北山洋晚志留世—早泥盆世构造演化:内蒙古白云山蛇绿混杂岩带南部侵入岩年代学、地球化学的制约

doi:10.19657/j.geoscience.1000-8527.2021.069

摘要/Abstract

摘要：

内蒙古北山白云山蛇绿混杂岩带南部中酸性侵入岩主要以脉岩形式产出。采用LA-ICP-MS锆石U-Pb定年和岩石地球化学分析,对脉岩的岩石类型、年代学、构造背景等进行研究,为北山洋的拼合碰撞时限提供年代学约束。研究结果显示:石英闪长岩的年龄为(420.0±1.0) Ma,花岗闪长岩的年龄为(404.6±2.6) Ma,表明脉岩形成时期为晚志留世—早泥盆世。中酸性侵入岩脉SiO₂含量为58.38%~69.46%,K₂O含量为0.74%~1.38%,Al₂O₃含量为15.54%~16.95%,Na₂O含量为4.15%~5.36%,岩石类型为钙碱性石英闪长岩和过铝质低钾拉斑系列的花岗闪长岩。石英闪长岩与花岗闪长岩源于陆缘火山弧区和同碰撞区,二者轻稀土元素相对重稀土元素明显富集,δEu负异常,高场强元素Ta、Nb亏损,显示出岛弧环境的典型特征,表明由于洋壳俯冲作用,研究区在晚志留世—早泥盆世发育了岛弧岩浆岩侵入体。随着俯冲作用深入,北山洋在晚志留世—早泥盆世早期完成闭合碰撞,并在研究区形成同碰撞花岗岩,碰撞时间应早于(404.6±2.6) Ma。

关键词: 内蒙古白云山, 火山弧同碰撞期, 中-酸性侵入岩脉, 年代学, 地球化学

Abstract:

Intermediate-felsic intrusive rocks occur mainly as dykes in the southern part of the Baiyunshan ophiolite mélange belt in the Beishan Orogen, Inner Mongolia. LA-ICP-MS zircon U-Pb dating and whole-rock geochemical analysis were performed to study the rock type, geochronology and tectonic setting of the dykes. Meanwhile, it provides chronological constraints for the timing of the Beishan ocean closure. The results show that the intermediate-felsic dykes have SiO₂=58.38%-69.46%, K₂O=0.74%-1.38%, Al₂O₃=15.54%-16.95%, and Na₂O=4.15%-5.36%. The rocks are calc-alkaline quartz diorite and peraluminous tholeiitic granodiorite. Zircon U-Pb ages of the quartz diorite and granodiorite are (420.0±1.0) Ma and (404.6±2.6) Ma, respectively, suggesting the dykes were intruded in the Late Silurian-Early Devonian. The quartz diorite and granodiorite were likely derived from a continental-margin volcanic arc and syn-collisional setting. The clear LREE/HREE enrichments and high field strength element (HFSE, e.g., Ta and Nb) depletions are typical of island arc affinity, which shows the occurrence of island arc magmatism in the Late Silurian-Early Devonian led by oceanic crust subduction. With the progress of subduction, the Beishan ocean may have closed completely in the Late Silurian-Early Devonian to form syn-collisional granites in the study area. The collision time should be before (404.6±2.6) Ma.

Key words: Baiyunshan, Inner Mongolia, volcano arc collision, intermediate-felsic dyke, geochronology, geochemistry

中图分类号:

程先钰, 田健, 段霄龙, 赵泽南, 任邦方, 张永. 北山洋晚志留世—早泥盆世构造演化:内蒙古白云山蛇绿混杂岩带南部侵入岩年代学、地球化学的制约[J]. 现代地质, 2022, 36(01): 295-306.

CHENG Xianyu, TIAN Jian, DUAN Xiaolong, ZHAO Zenan, REN Bangfang, ZHANG Yong. Late Silurian to Early Devonian Tectonic Evolution of Beishanyang: Constraints from Geochronology and Geochemistry of Intrusive Rocks in Southern Baiyunshan Ophiolitic Mélange Belt, Inner Mongolia[J]. Geoscience, 2022, 36(01): 295-306.

图/表 9

参考文献 45

[1]	JAHN B M. The Central Asian Orogenic Belt and growth of the continental crust in the Phanerozoic[M]// MAPASJ, FLETCHERC J N, ALIJ R, et al. Aspects of the Tectonic Evolution of China. London: Geological Society, 2004: 73-100.
[2]	XIAO W, MAO Q G, WINDLEY B F, et al. Paleozoic multiple accretionary and collisional processes of the Beishan orogenic collage[J]. American Journal of Science, 2010, 310: 1553-1594. DOI URL
[3]	SONG D F, XIAO W J, HAN C M, et al. Progressive accretionary tectonics of the Beishan orogenic collage, Southern Altaids: insights from zircon U-Pb and Hf isotopic data of high-grade complexes[J]. Precambrian Research, 2013, 227: 368-388. DOI URL
[4]	JAHN B M, WU F Y, CHEN B. Granitoids of the Central Asian Orogenic Belt and continental growth in the Phanerozoic[J]. Earth Sciences:Transactions of the Royal Society of Edinburgh, 2000, 91(1/2):181-193.
[5]	KOVALENKO V I, YARMOLYUK V V, KOVACH V P, et al. Isotopic provinces, mechanism of generation and sources of the continental curst in the Central Asian mobile belt: geological and isotopic evidence[J]. Journal of Asian Earth Sciences, 2004, 23: 605-627. DOI URL
[6]	SENGOR A M C, NATAL’IN B A, BURTMAN V S. Evolution of the Altaid tectonic collage and Paleozoic crustal growth in Eurasia[J]. Nature, 1993, 364: 299-307. DOI URL
[7]	WINDLEY B F, ALEXEIEV D, XIAO W J, et al. Tectonic models for accretion of the Central Asian Orogenic Belt[J]. Journal of the Geological Society, London, 2007, 164:31-47. DOI URL
[8]	杨合群, 李英, 赵国斌, 等. 北山蛇绿岩特征及构造属性[J]. 西北地质, 2010, 43(1):26-36.
[9]	GILLESPIE J, GLORIE S, XIAO W J, et al. Mesozoic reactivation of the Beishan, southern Central Asian Orogenic Belt: Insights from low-temperature thermochronology[J]. Gondwana Research, 2017, 43:107-122. DOI URL
[10]	DING J X, HAN C M, XIAO W J, et al. Geochronology,geochemistry and Sr-Nd isotopes of the granitic rocks associated with tungsten deposits in Beishan district, NW China, Central Asian Orogenic Belt: Petrogenesis, metallogenic and tectonic implications[J]. Ore Geology Reviews, 2017, 89:441-462. DOI URL
[11]	SONG D F, XIAO W J, WINDLEY B F, et al. Metamorphic complexes in accretionary orogens: Insights from the Beishan collage, southern Central Asian Orogenic Belt[J]. Tectonophy-sics, 2016, 688:135-147.
[12]	魏志军, 黄增保, 金霞, 等. 甘肃红石山地区蛇绿混杂岩地质特征[J]. 西北地质, 2004, 37(1):13-18.
[13]	于福生, 李金宝, 王涛. 东天山红柳河地区蛇绿岩U-Pb同位素年龄[J]. 地球学报, 2006, 27(3):213-216.
[14]	TIAN Z H, XIAO W J, WINDLEY B F, et al. Structure,age,and tectonic development of the Huoshishan-Niujuanzi ophiolitic mélange,Beishan,southernmost Altaids[J]. Gondwana Research, 2014, 25(2):820-841. DOI URL
[15]	孙立新, 张家辉, 任邦方, 等. 北山造山带白云山蛇绿混杂岩的地球化学特征、时代及地质意义[J]. 岩石矿物学杂志, 2017, 36(2):131-147.
[16]	胡新茁, 赵国春, 胡新悦, 等. 内蒙古北山地区月牙山蛇绿质构造混杂岩带地质特征、形成时代及大地构造意义[J]. 地质通报, 2015, 34(2/3):425-436.
[17]	侯青叶, 王忠, 刘金宝, 等. 北山月牙山蛇绿岩地球化学特征及 SHRIMP 定年[J]. 现代地质, 2012, 26(5):1008-1017.
[18]	李向民, 余吉远, 王国强, 等. 甘肃北山红柳园地区泥盆系三个井组和墩墩山群LA-ICP-MS锆石U-Pb测年及其意义[J]. 地质通报, 2011, 30(10):1501-1507.
[19]	程先钰, 滕学建, 田健, 等. 内蒙古北山造山带三个井组地球化学特征、同位素年龄及其构造环境[J]. 地质通报, 2020, 39(9):1461-1473.
[20]	田健, 段霄龙. 内蒙古北山地区月牙山、儿驼山幅1∶5万区域地质调查[R]. 天津: 中国地质调查局天津地质调查中心, 2018.
[21]	田健, 辛后田, 滕学建, 等. 内蒙古北山造山带白云山地区上泥盆统墩墩山组火山岩的厘定及其构造意义[J]. 岩石学报, 2019, 36(2):509-525.
[22]	LIU Y S, GAO S, HU Z C, et al. Continental and oceanic crust recycling-induced melt-peridotite interactions in the Trans-North China Orogen: U-Pb dating, Hf isotopes and trace elements in zircons of mantle xenoliths[J]. Journal of Petrology, 2010, 51(1/2): 537-571. DOI URL
[23]	LUDWIG K R. Isoplot 3.00: A Geochronological Toolkit for Microsoft Excel[J]. Berkeley:Berkeley Geochronology Center, 2003:39.
[24]	CHEN F K, HEGNER E, TODT W. Zircon ages, Nd isotopic and chemical compositions of orthogneisses from the Black Forest, Germany: Evidence for a Cambrian magmatic arc[J]. Interna-tional Journal of Earth Sciences, 2000, 88:791-802.
[25]	CHEN F K, SIEBELl W, SATIR M, et al. Geochronology of the Karadere basement(NW Turkey)and implications for the geological evolution of the Istanbul zone[J]. International Journal of Earth Sciences, 2002, 91:469-481. DOI URL
[26]	BELOUSOVA E, GRIFFIN W, O’REILLY S Y, et al. Igneous zircon: trace element composition as an Indicator of source rock type[J]. Contributions to Mineralogy and Petrology, 2002, 143(5): 602-622. DOI URL
[27]	HOSKIN P W O. Metamorphic zircon formation by solid-state recrystallization of protolith igneous zircon[J]. Journal of Metamorphic Geology, 2000, 18(4): 423-439. DOI URL
[28]	王立武, 王颖, 杨静, 等. 用碎屑锆石SHRIMP年代学方法恢复松辽盆地南部前中生代基底的源区特征[J]. 地学前缘, 2007, 14(4): 151-158.
[29]	莫宣学, 赵志丹, 邓晋福, 等. 印度-亚洲大陆主碰撞过程与火山作用相应[J]. 地学前缘, 2003, 13(3):135-148.
[30]	SUN S S, MCDONOUGH W F. Chemical and isotopic systematics of oceanic basalts: implications for mantle composition and processes[J]. Geological Society, London, Special Publications, 1989, 42:313-345. DOI URL
[31]	王永文, 颜丹平, 刘红旭, 等. 西天山伊犁地块北缘桦木沟高分异Ⅰ型花岗岩年代学、地球化学及其构造意义[J]. 现代地质, 2015, 29(3):529-541.
[32]	AO S J, XIAO W J, HAN C M, et al. Cambrian to Early Silurian Ophiolite and Accretionary Processes in the Beishan Collage, NW China: Implications for the Architecture of the Southern Altaids[M]. Cambridge: Cambridge University Press, 2012: 606-625.
[33]	GUO Q Q, XIAO W J, HOU Q L, et al. Construction of Late Devonian Dundunshan arc in the Beishan orogen and its implication for tectonics of southern Central Asian Orogenic Belt[J]. Lithos, 2014, 184: 361-378.
[34]	GUO Q Q, CHUN S L, XIAO W J, et al. Petrogenesis and tectonic implications of Late Devonian arc volcanic rocks in southern Beishan orogen, NW China: Geochemical and Nd-Sr-Hf isotopic constraints[J]. Lithos, 2017, 278/281: 84-96. DOI URL
[35]	ZHU J, LV X B, PENG S G. U-Pb zircon geochronology, geochemistry and tectonic implications of the Early Devonian grani-toids in the Liuyuan area, Beishan, NW China[J]. Geosciences Journal, 2016, 20(5):609-625. DOI URL
[36]	何世平, 任秉琛, 姚文光, 等. 甘肃内蒙古北山地区构造单元划分[J]. 西北地质, 2002, 35(4):30-39.
[37]	朱世海, 李琦, 李琼玉, 等. 阿拉善地区乌力吉花岗岩地球化学特征及地球动力学意义[J]. 科学技术与工程, 2019, 34(19):56-66.
[38]	LIU Q, ZHAO G C, SUN M, et al. Ages and tectonic implications of Neoproterozoic ortho-and paragneisses in the Beishan Orogenic Belt, China[J]. Precambrian Research, 2015, 266: 551-578. DOI URL
[39]	SHI Y R, ZHANG W, KRONER A, et al. Cambrian Ophiolite complexes in the Beishan area, China, southern margin of the Central Asian Orogenic Belt[J]. Journal of Asian Earth Sciences, 2018, 153:193-205. DOI URL
[40]	李杰豪, 侯读杰, 曹兰柱, 等. 二连盆地赛汉塔拉凹陷腾二段低熟油地球化学特征和油源对比[J]. 现代地质, 2021, 35(2):315-325.
[41]	张善明, 兰生科, 贺中银, 等. 内蒙古北山额勒根乌兰乌拉一带土壤测量地球化学特征及找矿方向[J]. 现代地质, 2018, 32(4):655-666.
[42]	李杰, 丛殿阁, 古艳春, 等. 内蒙古阿拉善地块北缘查干敖包一带二长花岗岩锆石定年、地球化学特征及其构造意义[J]. 现代地质, 2021, 35(2):514-522.
[43]	张竞, 王旭升, 贾凤超, 等. 对内蒙古阿拉善西部地下水流向问题的新认识[J]. 现代地质, 2015, 29(1):213-219.
[44]	毕君辉, 葛文春, 周红英, 等. 黑龙江省东北部勤得利-街津口地区基性侵入岩的锆石U-Pb年龄及其地质意义[J]. 华北地质, 2021, 44(1):1-3.
[45]	田健, 段霄龙, 程先钰. 北山造山带中部晚志留世-早泥盆世侵入岩源区特征及其反映的陆壳增生机制[J]. 地质调查与研究, 2020, 43(3): 207-223.

样品号及点号	含量/10^-6		Th/U	同位素比值				年龄/Ma
样品号及点号	Th	U	Th/U	²⁰⁷Pb/²⁰⁶Pb ±1σ	²⁰⁷Pb/²³⁵U ±1σ		²⁰⁶Pb/²³⁸U ±1σ	²⁰⁷Pb/²⁰⁶Pb ±1σ	²⁰⁷Pb/²³⁵U ±1σ	²⁰⁶Pb/²³⁸U ±1σ
TW3422.1	379	429	0.88	0.055 2±0.000 6		0.510 2±0.007 3	0.067 1±0.000 7	420±26	419±6	418±5
TW3422.2	396	448	0.88	0.055 3±0.000 6		0.511 3±0.006 7	0.067 0±0.000 7	426±26	419±6	418±4
TW3422.3	1 055	977	1.08	0.055 0±0.000 6		0.511 5±0.006 9	0.067 4±0.000 7	413±25	419±6	421±4
TW3422.4	675	625	1.08	0.055 6±0.000 7		0.513 6±0.007 2	0.067 0±0.000 6	436±28	421±6	418±4
TW3422.5	377	450	0.84	0.054 6±0.000 6		0.512 5±0.007 0	0.068 0±0.000 7	397±27	420±6	424±4
TW3422.6	315	365	0.86	0.055 7±0.000 7		0.519 8±0.008 5	0.067 7±0.000 8	441±28	425±7	422±5
TW3422.7	909	858	1.06	0.054 4±0.000 6		0.508 4±0.007 0	0.067 7±0.000 7	390±25	417±6	422±5
TW3422.8	465	467	1.00	0.055 4±0.000 6		0.512 2±0.007 1	0.067 1±0.000 7	428±26	420±6	418±5
TW3422.9	88	173	0.51	0.055 4±0.001 0		0.513 4±0.010 0	0.067 2±0.000 7	428±39	421±8	419±5
TW3422.10	353	446	0.79	0.054 8±0.000 6		0.509 8±0.006 8	0.067 5±0.000 7	403±26	418±6	421±4
TW3422.11	268	362	0.74	0.055 1±0.000 7		0.512 5±0.007 0	0.067 5±0.000 7	415±26	420±6	421±4
TW3422.12	440	367	1.20	0.054 9±0.002 1		0.512 2±0.021 2	0.067 7±0.000 8	406±86	420±17	422±5
TW3422.13	349	390	0.89	0.054 9±0.000 7		0.510 2±0.007 1	0.067 4±0.000 7	408±28	419±6	420±4
TW3422.14	450	513	0.88	0.054 9±0.000 6		0.511 0±0.006 8	0.067 5±0.000 7	408±26	419±6	421±4
TW3422.15	340	461	0.74	0.054 5±0.000 6		0.508 3±0.007 0	0.067 7±0.000 7	390±26	417±6	422±4
TW3422.16	396	527	0.75	0.054 6±0.000 6		0.507 9±0.007 4	0.067 5±0.000 8	395±26	417±6	421±5
TW3422.17	463	461	1.00	0.055 7±0.000 7		0.515 6±0.007 1	0.067 2±0.000 7	440±26	422±6	419±4
TW3422.18	140	240	0.59	0.055 0±0.001 1		0.510 3±0.012 8	0.067 3±0.000 8	410±43	419±11	420±5
TW3422.19	358	365	0.98	0.055 0±0.000 7		0.509 6±0.007 4	0.067 2±0.000 7	413±27	418±6	419±4
TW3422.20	359	338	1.06	0.054 8±0.000 7		0.509 3±0.007 4	0.067 4±0.000 7	404±28	418±6	420±4
TW3422.21	264	366	0.72	0.055 2±0.000 7		0.508 4±0.007 1	0.066 8±0.000 7	420±27	417±6	417±4
TW3422.22	382	417	0.92	0.054 9±0.000 6		0.507 5±0.006 9	0.067 0±0.000 7	410±26	417±6	418±4
TW3422.23	948	891	1.06	0.055 5±0.000 6		0.512 0±0.007 0	0.066 9±0.000 7	433±25	420±6	417±5
TW3422.24	395	528	0.75	0.055 5±0.000 6		0.512 2±0.006 8	0.067 0±0.000 7	431±26	420±6	418±4
TW3424-1.01	15	36	0.41	0.053 5±0.004 3		0.491 9±0.040 2	0.066 6±0.000 8	351±181	406±33	416±4
TW3424-1.02	39	59	0.66	0.055 2±0.002 7		0.493 3±0.024 2	0.064 8±0.000 7	419±108	407±20	405±4
TW3424-1.03	13	27	0.47	0.056 6±0.005 0		0.510 5±0.045 4	0.065 4±0.000 8	476±195	419±37	409±5
TW3424-1.04	17	30	0.56	0.055 3±0.004 1		0.495 0±0.036 8	0.065 0±0.000 7	423±166	408±30	406±5
TW3424-1.05	11	23	0.50	0.056 7±0.007 3		0.472 4±0.061 2	0.060 4±0.000 9	481±286	393±51	378±6
TW3424-1.06	31	50	0.62	0.053 0±0.002 5		0.482 3±0.023 5	0.066 0±0.000 7	330±108	400±19	412±4
TW3424-1.07	21	44	0.49	0.056 1±0.002 9		0.506 2±0.026 5	0.065 5±0.000 7	454±113	416±22	409±4
TW3424-1.08	13	28	0.45	0.053 8±0.004 6		0.498 6±0.043 0	0.067 2±0.000 8	364±192	411±35	419±5
TW3424-1.09	10	29	0.36	0.055 6±0.005 8		0.488 8±0.049 8	0.063 8±0.000 8	435±232	404±41	399±5
TW3424-1.10	17	40	0.44	0.057 5±0.004 1		0.509 5±0.035 6	0.064 2±0.000 7	512±156	418±29	401±5
TW3424-1.11	108	67	1.61	0.055 2±0.005 0		0.428 0±0.039 0	0.056 2±0.000 6	421±201	362±33	353±4
TW3424-1.12	30	42	0.71	0.055 4±0.003 5		0.494 2±0.031 3	0.064 7±0.000 7	427±141	408±26	404±4
样品号及点号	含量/10^-6		Th/U	同位素比值				年龄/Ma
样品号及点号	Th	U	Th/U	²⁰⁷Pb/²⁰⁶Pb ±1σ	²⁰⁷Pb/²³⁵U ±1σ		²⁰⁶Pb/²³⁸U ±1σ	²⁰⁶Pb/²³⁸U ±1σ	²⁰⁷Pb/²³⁵U ±1σ	²⁰⁷Pb/²⁰⁶Pb ±1σ
TW3424-1.13	16	39	0.41	0.053 8±0.004 1		0.486 0±0.037 9	0.065 5±0.000 7	364±174	402±31	409±5
TW3424-1.14	19	44	0.43	0.056 0±0.003 1		0.502 0±0.028 6	0.065 0±0.000 7	454±124	413±24	406±5
TW3424-1.15	32	55	0.59	0.054 5±0.002 4		0.479 8±0.021 2	0.063 8±0.000 7	393±97	398±18	399±4
TW3424-1.16	30	51	0.59	0.056 2±0.002 4		0.490 3±0.021 1	0.063 3±0.000 7	459±94	405±17	396±4
TW3424-1.17	18	47	0.39	0.053 9±0.002 6		0.487 5±0.024 3	0.065 6±0.000 7	368±109	403±20	409±4
TW3424-1.18	14	35	0.41	0.056 3±0.003 6		0.487 5±0.031 9	0.062 8±0.000 7	465±143	403±26	392±4
TW3424-1.19	14	33	0.44	0.053 5±0.004 1		0.473 4±0.036 0	0.064 2±0.000 7	351±172	394±30	401±5
TW3424-1.20	28	45	0.63	0.053 9±0.003 1		0.475 5±0.028 3	0.064 0±0.000 8	366±131	395±24	400±5
TW3424-1.21	29	50	0.57	0.054 4±0.002 9		0.479 5±0.026 2	0.063 9±0.000 7	387±121	398±22	400±4
TW3424-1.22	27	44	0.61	0.054 2±0.003 0		0.491 8±0.027 4	0.065 8±0.000 7	381±124	406±23	411±4
TW3424-1.23	28	68	0.41	0.053 5±0.001 9		0.481 9±0.017 6	0.065 3±0.000 7	352±80	399±15	408±4
TW3424-1.24	22	59	0.38	0.054 0±0.002 5		0.486 7±0.022 9	0.065 3±0.000 7	373±103	403±19	408±4

样品号及点号	含量/10^-6		Th/U	同位素比值				年龄/Ma
样品号及点号	Th	U	Th/U	²⁰⁷Pb/²⁰⁶Pb ±1σ	²⁰⁷Pb/²³⁵U ±1σ		²⁰⁶Pb/²³⁸U ±1σ	²⁰⁷Pb/²⁰⁶Pb ±1σ	²⁰⁷Pb/²³⁵U ±1σ	²⁰⁶Pb/²³⁸U ±1σ
TW3422.1	379	429	0.88	0.055 2±0.000 6		0.510 2±0.007 3	0.067 1±0.000 7	420±26	419±6	418±5
TW3422.2	396	448	0.88	0.055 3±0.000 6		0.511 3±0.006 7	0.067 0±0.000 7	426±26	419±6	418±4
TW3422.3	1 055	977	1.08	0.055 0±0.000 6		0.511 5±0.006 9	0.067 4±0.000 7	413±25	419±6	421±4
TW3422.4	675	625	1.08	0.055 6±0.000 7		0.513 6±0.007 2	0.067 0±0.000 6	436±28	421±6	418±4
TW3422.5	377	450	0.84	0.054 6±0.000 6		0.512 5±0.007 0	0.068 0±0.000 7	397±27	420±6	424±4
TW3422.6	315	365	0.86	0.055 7±0.000 7		0.519 8±0.008 5	0.067 7±0.000 8	441±28	425±7	422±5
TW3422.7	909	858	1.06	0.054 4±0.000 6		0.508 4±0.007 0	0.067 7±0.000 7	390±25	417±6	422±5
TW3422.8	465	467	1.00	0.055 4±0.000 6		0.512 2±0.007 1	0.067 1±0.000 7	428±26	420±6	418±5
TW3422.9	88	173	0.51	0.055 4±0.001 0		0.513 4±0.010 0	0.067 2±0.000 7	428±39	421±8	419±5
TW3422.10	353	446	0.79	0.054 8±0.000 6		0.509 8±0.006 8	0.067 5±0.000 7	403±26	418±6	421±4
TW3422.11	268	362	0.74	0.055 1±0.000 7		0.512 5±0.007 0	0.067 5±0.000 7	415±26	420±6	421±4
TW3422.12	440	367	1.20	0.054 9±0.002 1		0.512 2±0.021 2	0.067 7±0.000 8	406±86	420±17	422±5
TW3422.13	349	390	0.89	0.054 9±0.000 7		0.510 2±0.007 1	0.067 4±0.000 7	408±28	419±6	420±4
TW3422.14	450	513	0.88	0.054 9±0.000 6		0.511 0±0.006 8	0.067 5±0.000 7	408±26	419±6	421±4
TW3422.15	340	461	0.74	0.054 5±0.000 6		0.508 3±0.007 0	0.067 7±0.000 7	390±26	417±6	422±4
TW3422.16	396	527	0.75	0.054 6±0.000 6		0.507 9±0.007 4	0.067 5±0.000 8	395±26	417±6	421±5
TW3422.17	463	461	1.00	0.055 7±0.000 7		0.515 6±0.007 1	0.067 2±0.000 7	440±26	422±6	419±4
TW3422.18	140	240	0.59	0.055 0±0.001 1		0.510 3±0.012 8	0.067 3±0.000 8	410±43	419±11	420±5
TW3422.19	358	365	0.98	0.055 0±0.000 7		0.509 6±0.007 4	0.067 2±0.000 7	413±27	418±6	419±4
TW3422.20	359	338	1.06	0.054 8±0.000 7		0.509 3±0.007 4	0.067 4±0.000 7	404±28	418±6	420±4
TW3422.21	264	366	0.72	0.055 2±0.000 7		0.508 4±0.007 1	0.066 8±0.000 7	420±27	417±6	417±4
TW3422.22	382	417	0.92	0.054 9±0.000 6		0.507 5±0.006 9	0.067 0±0.000 7	410±26	417±6	418±4
TW3422.23	948	891	1.06	0.055 5±0.000 6		0.512 0±0.007 0	0.066 9±0.000 7	433±25	420±6	417±5
TW3422.24	395	528	0.75	0.055 5±0.000 6		0.512 2±0.006 8	0.067 0±0.000 7	431±26	420±6	418±4
TW3424-1.01	15	36	0.41	0.053 5±0.004 3		0.491 9±0.040 2	0.066 6±0.000 8	351±181	406±33	416±4
TW3424-1.02	39	59	0.66	0.055 2±0.002 7		0.493 3±0.024 2	0.064 8±0.000 7	419±108	407±20	405±4
TW3424-1.03	13	27	0.47	0.056 6±0.005 0		0.510 5±0.045 4	0.065 4±0.000 8	476±195	419±37	409±5
TW3424-1.04	17	30	0.56	0.055 3±0.004 1		0.495 0±0.036 8	0.065 0±0.000 7	423±166	408±30	406±5
TW3424-1.05	11	23	0.50	0.056 7±0.007 3		0.472 4±0.061 2	0.060 4±0.000 9	481±286	393±51	378±6
TW3424-1.06	31	50	0.62	0.053 0±0.002 5		0.482 3±0.023 5	0.066 0±0.000 7	330±108	400±19	412±4
TW3424-1.07	21	44	0.49	0.056 1±0.002 9		0.506 2±0.026 5	0.065 5±0.000 7	454±113	416±22	409±4
TW3424-1.08	13	28	0.45	0.053 8±0.004 6		0.498 6±0.043 0	0.067 2±0.000 8	364±192	411±35	419±5
TW3424-1.09	10	29	0.36	0.055 6±0.005 8		0.488 8±0.049 8	0.063 8±0.000 8	435±232	404±41	399±5
TW3424-1.10	17	40	0.44	0.057 5±0.004 1		0.509 5±0.035 6	0.064 2±0.000 7	512±156	418±29	401±5
TW3424-1.11	108	67	1.61	0.055 2±0.005 0		0.428 0±0.039 0	0.056 2±0.000 6	421±201	362±33	353±4
TW3424-1.12	30	42	0.71	0.055 4±0.003 5		0.494 2±0.031 3	0.064 7±0.000 7	427±141	408±26	404±4
样品号及点号	含量/10^-6		Th/U	同位素比值				年龄/Ma
样品号及点号	Th	U	Th/U	²⁰⁷Pb/²⁰⁶Pb ±1σ	²⁰⁷Pb/²³⁵U ±1σ		²⁰⁶Pb/²³⁸U ±1σ	²⁰⁶Pb/²³⁸U ±1σ	²⁰⁷Pb/²³⁵U ±1σ	²⁰⁷Pb/²⁰⁶Pb ±1σ
TW3424-1.13	16	39	0.41	0.053 8±0.004 1		0.486 0±0.037 9	0.065 5±0.000 7	364±174	402±31	409±5
TW3424-1.14	19	44	0.43	0.056 0±0.003 1		0.502 0±0.028 6	0.065 0±0.000 7	454±124	413±24	406±5
TW3424-1.15	32	55	0.59	0.054 5±0.002 4		0.479 8±0.021 2	0.063 8±0.000 7	393±97	398±18	399±4
TW3424-1.16	30	51	0.59	0.056 2±0.002 4		0.490 3±0.021 1	0.063 3±0.000 7	459±94	405±17	396±4
TW3424-1.17	18	47	0.39	0.053 9±0.002 6		0.487 5±0.024 3	0.065 6±0.000 7	368±109	403±20	409±4
TW3424-1.18	14	35	0.41	0.056 3±0.003 6		0.487 5±0.031 9	0.062 8±0.000 7	465±143	403±26	392±4
TW3424-1.19	14	33	0.44	0.053 5±0.004 1		0.473 4±0.036 0	0.064 2±0.000 7	351±172	394±30	401±5
TW3424-1.20	28	45	0.63	0.053 9±0.003 1		0.475 5±0.028 3	0.064 0±0.000 8	366±131	395±24	400±5
TW3424-1.21	29	50	0.57	0.054 4±0.002 9		0.479 5±0.026 2	0.063 9±0.000 7	387±121	398±22	400±4
TW3424-1.22	27	44	0.61	0.054 2±0.003 0		0.491 8±0.027 4	0.065 8±0.000 7	381±124	406±23	411±4
TW3424-1.23	28	68	0.41	0.053 5±0.001 9		0.481 9±0.017 6	0.065 3±0.000 7	352±80	399±15	408±4
TW3424-1.24	22	59	0.38	0.054 0±0.002 5		0.486 7±0.022 9	0.065 3±0.000 7	373±103	403±19	408±4

样品号	岩性	SiO₂	Al₂O₃	Fe₂O₃	FeO	CaO	MgO	K₂O	Na₂O	TiO₂	P₂O₅	MnO	烧失量
YQ3422-1	石英闪长岩	58.46	16.83	1.82	4.36	5.74	3.33	1.38	4.15	1.29	0.23	0.11	1.81
YQ3422-2	石英闪长岩	58.38	16.95	2.05	4.52	5.41	3.21	1.31	4.34	1.21	0.24	0.12	1.78
YQ3424-1	花岗闪长岩	69.20	15.72	1.30	1.20	2.66	1.59	0.74	5.36	0.32	0.08	0.06	1.64
YQ3424-2	花岗闪长岩	69.46	15.54	1.04	1.31	2.76	1.50	0.84	5.32	0.34	0.08	0.04	1.62
样品号	岩性	总量	Na₂O+K₂O	Na₂O/K₂O	Cu	Pb	Zn	Cr	Ni	Co	Li	Rb	Cs
YQ3422-1	石英闪长岩	99.51	5.53	3.01	12.90	7.10	57.8	34.7	16.00	20.50	20.20	33.1	1.55
YQ3422-2	石英闪长岩	99.52	5.65	3.31	24.90	7.74	75.7	29.1	13.90	20.50	14.40	40.3	1.88
YQ3424-1	花岗闪长岩	99.87	6.10	7.24	2.87	3.90	27.0	19.5	9.26	6.62	5.87	23.3	3.20
YQ3424-2	花岗闪长岩	99.85	6.16	6.33	3.11	3.72	26.6	18.1	8.81	6.42	5.23	29.8	2.82
样品号	岩性	Bi	Sr	Ba	V	Sc	Y	Nb	Ta	Zr	Hf	Be	Ga
YQ3422-1	石英闪长岩	0.028	301	278	129.0	16.60	28.50	7.29	0.68	205	5.86	1.51	19.1
YQ3422-2	石英闪长岩	0.027	304	297	137.0	14.80	26.90	6.13	0.58	114	3.58	1.52	19.0
YQ3424-1	花岗闪长岩	0.015	303	99	32.9	2.25	7.47	2.27	0.21	159	4.05	0.84	13.4
YQ3424-2	花岗闪长岩	0.016	276	123	33.5	2.36	7.46	2.39	0.22	128	3.81	1.00	13.3
样品号	岩性	U	Th	La	Ce	Pr	Nd	Sm	Eu	Gd	Tb	Dy	Ho
YQ3422-1	石英闪长岩	1.15	4.87	17.00	36.3	5.10	22.00	5.20	1.36	5.90	0.97	5.78	1.12
YQ3422-2	石英闪长岩	0.91	3.89	15.80	32.9	4.72	20.50	4.97	1.47	5.53	0.90	5.39	1.05
YQ3424-1	花岗闪长岩	0.51	1.78	6.30	14.2	1.83	7.54	1.73	0.50	1.79	0.28	1.51	0.30
YQ3424-2	花岗闪长岩	0.58	2.01	6.29	13.3	1.75	7.10	1.59	0.52	1.72	0.26	1.52	0.28
样品号	岩性	Er	Tm	Yb	Lu	REE	LREE	HREE	LREE/HREE	δEu	δCe	(La/Yb)_N
YQ3422-1	石英闪长岩	3.04	0.43	2.95	0.45	107.6	86.96	20.64	4.21	0.75	0.96	4.13
YQ3422-2	石英闪长岩	2.81	0.40	2.69	0.40	99.53	80.36	19.17	4.19	0.86	0.93	4.21
YQ3424-1	花岗闪长岩	0.74	0.11	0.70	0.11	37.64	32.10	5.54	5.79	0.87	1.03	6.46
YQ3424-2	花岗闪长岩	0.74	0.11	0.75	0.11	36.04	30.55	5.49	5.56	0.96	0.98	6.02

样品号	岩性	SiO₂	Al₂O₃	Fe₂O₃	FeO	CaO	MgO	K₂O	Na₂O	TiO₂	P₂O₅	MnO	烧失量
YQ3422-1	石英闪长岩	58.46	16.83	1.82	4.36	5.74	3.33	1.38	4.15	1.29	0.23	0.11	1.81
YQ3422-2	石英闪长岩	58.38	16.95	2.05	4.52	5.41	3.21	1.31	4.34	1.21	0.24	0.12	1.78
YQ3424-1	花岗闪长岩	69.20	15.72	1.30	1.20	2.66	1.59	0.74	5.36	0.32	0.08	0.06	1.64
YQ3424-2	花岗闪长岩	69.46	15.54	1.04	1.31	2.76	1.50	0.84	5.32	0.34	0.08	0.04	1.62
样品号	岩性	总量	Na₂O+K₂O	Na₂O/K₂O	Cu	Pb	Zn	Cr	Ni	Co	Li	Rb	Cs
YQ3422-1	石英闪长岩	99.51	5.53	3.01	12.90	7.10	57.8	34.7	16.00	20.50	20.20	33.1	1.55
YQ3422-2	石英闪长岩	99.52	5.65	3.31	24.90	7.74	75.7	29.1	13.90	20.50	14.40	40.3	1.88
YQ3424-1	花岗闪长岩	99.87	6.10	7.24	2.87	3.90	27.0	19.5	9.26	6.62	5.87	23.3	3.20
YQ3424-2	花岗闪长岩	99.85	6.16	6.33	3.11	3.72	26.6	18.1	8.81	6.42	5.23	29.8	2.82
样品号	岩性	Bi	Sr	Ba	V	Sc	Y	Nb	Ta	Zr	Hf	Be	Ga
YQ3422-1	石英闪长岩	0.028	301	278	129.0	16.60	28.50	7.29	0.68	205	5.86	1.51	19.1
YQ3422-2	石英闪长岩	0.027	304	297	137.0	14.80	26.90	6.13	0.58	114	3.58	1.52	19.0
YQ3424-1	花岗闪长岩	0.015	303	99	32.9	2.25	7.47	2.27	0.21	159	4.05	0.84	13.4
YQ3424-2	花岗闪长岩	0.016	276	123	33.5	2.36	7.46	2.39	0.22	128	3.81	1.00	13.3
样品号	岩性	U	Th	La	Ce	Pr	Nd	Sm	Eu	Gd	Tb	Dy	Ho
YQ3422-1	石英闪长岩	1.15	4.87	17.00	36.3	5.10	22.00	5.20	1.36	5.90	0.97	5.78	1.12
YQ3422-2	石英闪长岩	0.91	3.89	15.80	32.9	4.72	20.50	4.97	1.47	5.53	0.90	5.39	1.05
YQ3424-1	花岗闪长岩	0.51	1.78	6.30	14.2	1.83	7.54	1.73	0.50	1.79	0.28	1.51	0.30
YQ3424-2	花岗闪长岩	0.58	2.01	6.29	13.3	1.75	7.10	1.59	0.52	1.72	0.26	1.52	0.28
样品号	岩性	Er	Tm	Yb	Lu	REE	LREE	HREE	LREE/HREE	δEu	δCe	(La/Yb)_N
YQ3422-1	石英闪长岩	3.04	0.43	2.95	0.45	107.6	86.96	20.64	4.21	0.75	0.96	4.13
YQ3422-2	石英闪长岩	2.81	0.40	2.69	0.40	99.53	80.36	19.17	4.19	0.86	0.93	4.21
YQ3424-1	花岗闪长岩	0.74	0.11	0.70	0.11	37.64	32.10	5.54	5.79	0.87	1.03	6.46
YQ3424-2	花岗闪长岩	0.74	0.11	0.75	0.11	36.04	30.55	5.49	5.56	0.96	0.98	6.02
