滇西北羊拉铜矿床江边岩体岩石学、地球化学特征及锆石U-Pb年龄

doi:10.19657/j.geoscience.1000-8527.2020.02.01

摘要/Abstract

摘要：

羊拉铜矿是三江地区金沙江—哀牢山铜金成矿带的大型铜矿床,位于中咱微陆块与昌都—思茅地块相夹持的金沙江板块结合带,矿床与印支期侵入岩(花岗闪长岩体)有密切的时空成因联系。通过对江边花岗闪长斑岩体、花岗闪长岩体的地球化学研究,发现岩体富SiO₂、Al和大离子亲石元素,贫Fe、Mg、高场强元素,属准铝质-弱过铝质I型花岗岩;各岩石样品点均落入火山弧花岗岩和同碰撞花岗岩过渡区域,反映江边岩体属活动板块边缘产物,岩浆除幔源外,还混入了下地壳熔融物质。江边岩体锆石原位U-Pb定年分析得出2个花岗闪长斑岩(ZKJ1-1-14、ZKJ2-1-7)年龄为215 Ma、208 Ma,3个花岗闪长岩(ZKJ1-1-17、ZKJ2-1-6、ZKJ2-1-8)年龄为221 Ma、220 Ma和214 Ma,结合对路农、里农和贝吾花岗闪长岩体结晶年龄分析,得出羊拉矿区成矿岩体自南向北年龄逐渐变新的侵位序列;矿区内岩浆活动持续25 Ma,印证江边岩体同属俯冲-碰撞作用所致的造山期岛弧型花岗岩类,为碰撞后拉张背景的典型产物。

关键词: 花岗闪长岩, 地球化学, U-Pb定年, 羊拉铜矿床

Abstract:

Yangla copper deposit is a large deposit of Jinshajiang-Ailaoshan copper-gold metallogenic belt in Three-river area, which located in the bonding zone of Jinshajiang plate between Zhongza micro-continent fragment and Changdu-Simao block. The results show that the major elements of the Jiangbian granodiorite-rock mass is a typical I-type granite, with high SiO₂, Al and lithophile elements, and deficit of Fe, Mg and high field strength elements.Besides, the samples mainly fall into the transitional regions of volcanic-arc granite and syn-collision granite, which reflects the Jiangbian granodiorite pluton is the products of active plate margin, and the main magmatic fluid compositions are mantle and accompanied with input of melting of the crust. Zircon U-Pb dating by LA-ICP-MS method indicated that the ages of ZKJ1-1-14 and ZKJ2-1-7 granodiorite porphyry were 215 Ma and 208 Ma, and ZKJ1-1-17, ZKJ2-1-6 and ZKJ2-1-8 granodiorite were 221 Ma, 220 Ma and 214 Ma, respectively. Based on the crystallizing age of Lunong pluton, Linong pluton, Jiangbian pluton and Beiwu pluton, this paper hold that the magmatic intrusions tended to freshen from southern mining area to northern mining area. And the magmatism in the Jiangbian area was active for a long period (about 25 Ma). This research corroborated that the Jiangbian rock mass is a island-arc type granite associated subduction-collision and formed in post-collisional extensional environment.

Key words: granodiorite, geochemistry, U-Pb dating, Yangla copper deposit

中图分类号:

杨帆, 余璨, 坚润堂, 姚志华. 滇西北羊拉铜矿床江边岩体岩石学、地球化学特征及锆石U-Pb年龄[J]. 现代地质, 2020, 34(02): 215-232.

YANG Fan, YU Can, JIAN Runtang, YAO Zhihua. Characteristics of Petrology,Geochemistry and U-Pb Dating of Zircon from the Jiangbian Pluton in the Yangla Copper Deposit, Western Yunnan[J]. Geoscience, 2020, 34(02): 215-232.

图/表 24

参考文献 40

[1]	林仕良, 王立全. 云南德钦羊拉铜矿床构造特征[J]. 沉积与特提斯地质, 2004,24(3):48-51.
[2]	魏君奇, 陈开旭. 云南羊拉地区铜矿成矿系列[J]. 地质科技情报, 2004,23(2):21-24.
[3]	杨喜安, 刘家军, 韩思宇, 等. 云南羊拉铜矿床矿物组成、地球化学特征及其地质意义[J]. 现代地质, 2012,26(2):229-242.
[4]	杨喜安, 刘家军, 韩思宇, 等. 滇西羊拉铜矿床、鲁春铜铅锌矿床构造控矿特征[J]. 大地构造与成矿学, 2012,36(2):248-258.
[5]	何龙清, 战明国, 路远发. 滇西羊拉铜矿区层序地层划分及赋矿层位研究[J]. 华南地质与矿产, 1998(3):37-41.
[6]	余凤鸣, 战明国, 甘金木, 等. 滇西羊拉大型铜矿床石英构造岩微观构造与动力学分析[J]. 地质通报, 2000,19(1):92-99.
[7]	路远发, 陈开旭, 战明国. 羊拉地区含矿矽卡岩成因的地球化学证据[J]. 地球科学:中国地质大学学报, 1999,24(3):298-303.
[8]	路远发, 陈开旭, 黄慧兰. 云南羊拉地区不同类型铜矿床流体包裹体研究[J]. 地质科技情报, 2004,23(2):13-20.
[9]	路远发, 战明国, 陈开旭. 金沙江构造带嘎金雪山岩群玄武岩铀-铅同位素年龄[J]. 中国区域地质, 2000,19(2):155-158.
[10]	潘家永, 张乾, 李朝阳. 滇西羊拉铜矿稀土元素地球化学[J]. 矿物学报, 2000,20(1):44-49.
[11]	潘家永, 张乾, 马东升, 等. 滇西羊拉铜矿的稳定同位素地球化学研究[J]. 矿物学报, 2000,20(4):385-389.
[12]	陈开旭, 路远发, 魏君奇, 等. 滇西北羊拉铜矿区成矿地质背景及多期成矿作用[J]. 矿床地质, 2002,21(增刊):361-364.
[13]	战明国, 路远发, 陈式房, 等. 滇西德钦羊拉铜矿[M]. 武汉: 中国地质大学出版社, 1998: 1-163.
[14]	王立全, 侯增谦, 莫宣学, 等. 金沙江造山带碰撞后地壳伸展背景火山成因块状硫化物矿床的重要成矿环境[J]. 地质学报, 2002,76(4):541-556.
[15]	路远发, 战明国, 陈开旭, 等. 羊拉地区含矿矽卡岩流体包裹体特征及其成因意义[J]. 矿床地质, 1998,17(4):331-334.
[16]	魏君奇, 陈开旭, 魏福玉. 滇西羊拉地区构造-岩浆-成矿作用分析[J]. 华南地质与矿产, 2000(1):59-62.
[17]	曲晓明, 杨岳清, 李佑国. 从赋矿岩系岩石类型的多样性论羊拉铜矿的成因[J]. 矿床地质, 2004,23(4):431-442.
[18]	MEI Yanxiong, ZHANG Zhenfei, XU Yuanjin, et al. Metamorphic skarns in the Yangla Cu ore field, Northwest Yunnan Province, China[J]. Journal of Earth Science, 2018,29(3):508-519.
[19]	YANG X A, LIU J J, HAN S Y, et al. U-Pb dating of zircon from the Linong granodiorite, Re-Os dating of molybdnite from the ore body and their geological significance in Yangla copper deposit, Yunnan[J]. Acta Petrologica Sinica, 2011,27(9):2567-2576.
[20]	DENG Jun, WANG Changming, LI Gongjian. Style and process of the superimposed mineralization in the Sanjiang Tethys[J]. Acta Petrologica Sinica, 2012,28(5):1349-1361.
[21]	路远发, 陈开旭, 何龙清, 等. 德钦县羊拉铜矿区碳-氧同位素组成特征及其地质意义[J]. 地质论评, 2002,48(s1):225-229.
[22]	朱俊, 曾普胜, 曾礼传, 等. 滇西北羊拉铜矿区地层划分[J]. 地质学报, 2009,83(10):1415-1420.
[23]	朱俊, 李文昌, 曾普胜, 等. 滇西羊拉矿区层状铜矿床复合成因的地质地球化学证据[J]. 地质论评, 2011,57(3):337-349.
[24]	李洁, 陈文, 雍拥, 等. 云南羊拉铜矿区岩体边缘相岩石对矿床成因与时代的指示意义[J]. 岩石学报, 2014,30(8):2269-2278.
[25]	WANG Yanbin, HAN J, ZENG P S. U-Pb dating and Hf isotopic characteristics of zircons from granodiorite in Yangla copper deposit, Deqin County, Yunnan, Southwest China[J]. Acta Petrologica Sinica, 2010,26(6):1833-1844.
[26]	YANG Xi’an, LIU Jiajun, CAO Ye, et al. Geochemistry and S, Pb isotope of the Yangla copper deposit, western Yunnan, China: implication for ore genesis[J]. Lithos, 2012,144:231-240.
[27]	MIDDLEMOST E A K. Naming materials in the magma/igneous rock system[J]. Earth-Science Reviews, 1994,37(3/4) : 215-224.
[28]	WRIGHT J B. A simple alkalinity ratio and its application to questions of non-orogenic granite genesis[J]. Geological Magazine, 1969,106(4):370-384.
[29]	PECCERILLO A, TAYLOR S R. Geochemistry of Eocene calc-alkaline volcanic rocks from the Kastamonu area, Northern Turkey[J]. Contributions to Mineralogy & Petrology, 1975,58(1) : 63-81.
[30]	RICKWOOD P C. Boundary lines within petrologic diagrams which use oxides of major and minor elements[J]. Lithos, 1989,22(4) : 247-263.
[31]	ALTHERR R, HOLL A, HEGNER E, et al. High-potassium, calc-alkaline I-type plutonism in the European Variscides: northern Vosges (France) and northern Schwarzwald (Germany)[J]. Lithos, 2000,50(1/3):51-73.
[32]	SUN S S, MCDONOUGH W F. Chemical and isotopic systema-tics of oceanic basalts; implications for mantle composition and processes[J]. Geological Society of London Special Publications, 1989,42(1):313-345.
[33]	魏君奇, 战明国, 路远发, 等. 滇西德钦羊拉矿区花岗岩类地球化学[J]. 华南地质与矿产, 1997 ( 4):50-56.
[34]	PHARAOH T C, PEARCE J A. Geochemical evidence for the geotectonic setting of early Proterozoic metabolcanic sequences in Lwpland[J]. Precambrian Research, 1984,25:282-308.
[35]	杨喜安, 刘家军, 韩思宇, 等. 云南羊拉铜矿床里农花岗闪长岩体锆石U-Pb年龄、矿体辉钼矿Re-Os年龄及其地质意义[J]. 岩石学报, 2011,27(9):2567-2576.
[36]	杨德庭, 王彦斌. 滇西北羊拉铜矿床赋矿围岩的时代和物源区特征:锆石LA-MC-ICP-MS U-Pb年龄的制约[J]. 地质论评, 2015,61(3):594-608.
[37]	朱经经, 胡瑞忠, 毕献武, 等. 滇西北羊拉铜矿矿区花岗岩成因及其构造意义[J]. 岩石学报, 2011,27(9):2553-2566.
[38]	李波, 丁俊英, 黄智龙, 等. 滇西北羊拉大型铜矿床构造热液成矿作用的流体包裹体证据[J]. 昆明理工大学学报(自然科学版), 2018,43(3):25-36.
[39]	简平, 刘敦一, 孙晓猛. 滇西北白马雪山和鲁甸花岗岩基SHRIMP U-Pb年龄及其地质意义[J]. 地球学报, 2003,24(4):337-342.
[40]	孔会磊, 董国臣, 莫宣学, 等. 滇西三江地区临沧花岗岩的岩石成因:地球化学、锆石U-Pb年代学及Hf同位素约束[J]. 岩石学报, 2012,28(5):1438-1452.

氯化物	ZKJ1-1-5		ZKJ1-1-8					ZKJ1-1-17
氯化物	闪长玢岩		花岗闪长斑岩					花岗闪长岩
SiO₂	53.73	66.22		63.21	62.65	64.60	67.77		60.33	70.36
TiO₂	0.71	0.37		0.38	0.39	0.33	0.35		0.94	0.30
Al₂O₃	16.21	14.78		15.49	14.38	13.77	15.13		14.19	14.98
Fe₂O₃	1.20	0.32		0.63	2.26	0.85	0.66		1.70	0.47
FeO	6.39	3.37		2.73	0.80	2.16	2.94		6.89	2.10
MnO	0.13	0.067		0.11	0.078	0.068	0.08		0.16	0.03
MgO	4.79	1.72		1.51	1.07	1.20	1.39		3.40	0.91
CaO	7.59	2.93		3.29	5.57	4.76	3.45		4.00	2.16
Na₂O	2.78	3.94		0.08	1.44	0.084	2.99		2.46	2.86
K₂O	2.52	3.24		4.66	3.12	2.70	3.52		3.87	4.14
P₂O₅	0.13	0.09		0.08	0.09	0.08	0.08		0.20	0.09
H₂O⁺	2.49	1.87		2.63	3.09	3.52	1.18		1.25	1.06
H₂O^-	0.32	0.29		0.33	0.98	0.46	0.19		0.19	0.24
灼失量	3.65	2.81		7.75	8.08	9.34	1.50		1.67	1.45
总和	99.84	99.86		99.91	99.94	99.94	99.86		99.79	99.85
σ₄₃	2.37	2.17		1.03	0.98	0.33	1.69		2.26	1.78
A/CNK	0.77	0.97		1.39	0.90	1.17	1.01		0.92	1.14
DI	43.10	74.63		67.62	64.76	63.35	72.88		58.83	80.61
SI	27.08	13.63		15.7	12.54	17.17	12.05		18.55	8.67

氯化物	ZKJ1-1-5		ZKJ1-1-8					ZKJ1-1-17
氯化物	闪长玢岩		花岗闪长斑岩					花岗闪长岩
SiO₂	53.73	66.22		63.21	62.65	64.60	67.77		60.33	70.36
TiO₂	0.71	0.37		0.38	0.39	0.33	0.35		0.94	0.30
Al₂O₃	16.21	14.78		15.49	14.38	13.77	15.13		14.19	14.98
Fe₂O₃	1.20	0.32		0.63	2.26	0.85	0.66		1.70	0.47
FeO	6.39	3.37		2.73	0.80	2.16	2.94		6.89	2.10
MnO	0.13	0.067		0.11	0.078	0.068	0.08		0.16	0.03
MgO	4.79	1.72		1.51	1.07	1.20	1.39		3.40	0.91
CaO	7.59	2.93		3.29	5.57	4.76	3.45		4.00	2.16
Na₂O	2.78	3.94		0.08	1.44	0.084	2.99		2.46	2.86
K₂O	2.52	3.24		4.66	3.12	2.70	3.52		3.87	4.14
P₂O₅	0.13	0.09		0.08	0.09	0.08	0.08		0.20	0.09
H₂O⁺	2.49	1.87		2.63	3.09	3.52	1.18		1.25	1.06
H₂O^-	0.32	0.29		0.33	0.98	0.46	0.19		0.19	0.24
灼失量	3.65	2.81		7.75	8.08	9.34	1.50		1.67	1.45
总和	99.84	99.86		99.91	99.94	99.94	99.86		99.79	99.85
σ₄₃	2.37	2.17		1.03	0.98	0.33	1.69		2.26	1.78
A/CNK	0.77	0.97		1.39	0.90	1.17	1.01		0.92	1.14
DI	43.10	74.63		67.62	64.76	63.35	72.88		58.83	80.61
SI	27.08	13.63		15.7	12.54	17.17	12.05		18.55	8.67

元素	ZKJ1-1-5	ZKJ1-1-8	ZKJ1-1-12	ZKJ1-1-14	ZKJ2-1-7	ZKJ1-1-17	ZKJ2-1-6	ZKJ2-1-8
元素	闪长玢岩	花岗闪长斑岩				花岗闪长岩
V	130.00	50.00	47.40	53.80	47.80	46.30	74.90	44.30
Cr	34.90	10.10	7.66	9.66	8.73	11.10	18.20	8.87
Co	24.80	8.91	4.70	7.91	7.96	7.78	17.50	5.56
Ni	14.60	3.76	2.93	3.76	3.49	3.24	6.47	2.42
Cu	14.80	4.54	34.20	3.32	6.91	5.85	6.06	41.40
Zn	69.70	39.20	73.10	53.40	49.90	42.00	69.40	32.60
Ga	18.90	18.80	16.90	16.30	14.30	16.40	16.60	22.80
Rb	111.00	123.00	272.00	145.00	109.00	109.00	136.00	162.00
Sr	318.00	266.00	78.80	129.00	63.00	298.00	190.00	331.00
Zr	102.00	128.00	102.00	109.00	141.00	131.00	187.00	143.00
Nb	6.68	9.32	5.84	5.61	6.76	8.06	15.10	14.20
Mo	0.85	0.86	0.56	0.79	1.06	0.43	0.90	0.61
Cd	0.09	0.04	0.63	0.13	0.15	0.03	0.04	0.04
In	0.04	0.02	0.16	0.03	0.04	0.03	0.06	0.02
Cs	9.19	12.30	29.80	65.50	16.90	10.80	10.20	9.13
Ba	663.00	777.00	351.00	234.00	296.00	926.00	1 032.00	979.00
Hf	4.51	5.55	4.32	4.15	5.61	6.44	7.85	5.42
Ta	0.88	1.22	0.87	0.82	0.77	1.21	1.32	1.60
W	1.28	2.40	4.61	2.86	1.80	1.83	0.54	0.75
Tl	1.12	1.12	3.47	1.41	0.81	0.72	0.99	1.20
Pb	9.34	15.00	119.00	22.40	18.00	30.80	18.70	41.0
Bi	0.12	0.04	0.78	0.14	0.16	0.05	0.04	0.40
Th	10.80	15.80	17.10	16.90	21.10	19.70	18.80	20.60
U	1.77	5.22	3.55	3.72	3.61	4.25	2.28	8.98
P	584.00	419.00	342.00	417.00	322.00	337.00	744.00	475.00
Ti	4 504.00	2 485.00	1 703.00	1 706.00	1 740.00	2 078.00	4 929.00	2 318.00
F	201.00	339.00	811.00	391.00	313.00	369.00	692.00	343.00
Ag	0.06	0.05	0.47	0.11	0.08	0.04	0.05	0.07
Sn	2.83	2.69	39.20	4.27	6.60	3.01	6.56	2.53
B	17.80	18.60	226.00	121.00	79.50	25.80	10.30	24.90
As	5.80	3.90	51.00	11.00	19.00	10.20	5.30	1.50
Sb	0.71	1.21	29.60	0.82	0.92	0.75	0.45	0.26
Ge	1.80	1.48	1.72	0.68	1.08	1.32	1.68	1.34

元素	ZKJ1-1-5	ZKJ1-1-8	ZKJ1-1-12	ZKJ1-1-14	ZKJ2-1-7	ZKJ1-1-17	ZKJ2-1-6	ZKJ2-1-8
元素	闪长玢岩	花岗闪长斑岩				花岗闪长岩
V	130.00	50.00	47.40	53.80	47.80	46.30	74.90	44.30
Cr	34.90	10.10	7.66	9.66	8.73	11.10	18.20	8.87
Co	24.80	8.91	4.70	7.91	7.96	7.78	17.50	5.56
Ni	14.60	3.76	2.93	3.76	3.49	3.24	6.47	2.42
Cu	14.80	4.54	34.20	3.32	6.91	5.85	6.06	41.40
Zn	69.70	39.20	73.10	53.40	49.90	42.00	69.40	32.60
Ga	18.90	18.80	16.90	16.30	14.30	16.40	16.60	22.80
Rb	111.00	123.00	272.00	145.00	109.00	109.00	136.00	162.00
Sr	318.00	266.00	78.80	129.00	63.00	298.00	190.00	331.00
Zr	102.00	128.00	102.00	109.00	141.00	131.00	187.00	143.00
Nb	6.68	9.32	5.84	5.61	6.76	8.06	15.10	14.20
Mo	0.85	0.86	0.56	0.79	1.06	0.43	0.90	0.61
Cd	0.09	0.04	0.63	0.13	0.15	0.03	0.04	0.04
In	0.04	0.02	0.16	0.03	0.04	0.03	0.06	0.02
Cs	9.19	12.30	29.80	65.50	16.90	10.80	10.20	9.13
Ba	663.00	777.00	351.00	234.00	296.00	926.00	1 032.00	979.00
Hf	4.51	5.55	4.32	4.15	5.61	6.44	7.85	5.42
Ta	0.88	1.22	0.87	0.82	0.77	1.21	1.32	1.60
W	1.28	2.40	4.61	2.86	1.80	1.83	0.54	0.75
Tl	1.12	1.12	3.47	1.41	0.81	0.72	0.99	1.20
Pb	9.34	15.00	119.00	22.40	18.00	30.80	18.70	41.0
Bi	0.12	0.04	0.78	0.14	0.16	0.05	0.04	0.40
Th	10.80	15.80	17.10	16.90	21.10	19.70	18.80	20.60
U	1.77	5.22	3.55	3.72	3.61	4.25	2.28	8.98
P	584.00	419.00	342.00	417.00	322.00	337.00	744.00	475.00
Ti	4 504.00	2 485.00	1 703.00	1 706.00	1 740.00	2 078.00	4 929.00	2 318.00
F	201.00	339.00	811.00	391.00	313.00	369.00	692.00	343.00
Ag	0.06	0.05	0.47	0.11	0.08	0.04	0.05	0.07
Sn	2.83	2.69	39.20	4.27	6.60	3.01	6.56	2.53
B	17.80	18.60	226.00	121.00	79.50	25.80	10.30	24.90
As	5.80	3.90	51.00	11.00	19.00	10.20	5.30	1.50
Sb	0.71	1.21	29.60	0.82	0.92	0.75	0.45	0.26
Ge	1.80	1.48	1.72	0.68	1.08	1.32	1.68	1.34

元素	ZKJ1-1-5	ZKJ1-1-8	ZKJ1-1-12	ZKJ1-1-14	ZKJ2-1-7	ZKJ1-1-17	ZKJ2-1-6	ZKJ2-1-8
元素	闪长玢岩	花岗闪长斑岩				花岗闪长岩
Y	16.90	13.50	13.60	14.60	10.90	14.00	26.70	11.30
La	14.40	22.20	30.20	22.90	31.30	21.10	44.60	26.70
Ce	27.30	36.40	51.90	37.50	48.90	36.50	78.60	45.80
Pr	3.92	4.64	6.26	4.80	5.76	4.71	10.00	5.82
Nd	15.50	16.20	20.90	16.90	19.10	16.80	35.80	20.00
Sm	3.28	2.98	3.33	3.03	3.07	3.10	6.37	3.68
Eu	0.92	0.97	0.71	0.83	0.67	0.81	1.08	0.93
Gd	3.11	2.74	3.15	2.89	2.82	2.76	6.02	3.07
Tb	0.54	0.43	0.47	0.46	0.40	0.43	0.92	0.46
Dy	3.15	2.30	2.44	2.44	1.96	2.40	4.89	2.19
Ho	0.66	0.48	0.52	0.51	0.40	0.51	0.99	0.40
Er	1.85	1.36	1.50	1.49	1.12	1.49	2.81	1.07
Tm	0.35	0.26	0.28	0.30	0.22	0.29	0.54	0.19
Yb	2.02	1.53	1.61	1.68	1.15	1.71	2.91	1.08
Lu	0.27	0.21	0.22	0.24	0.19	0.27	0.41	0.17
ΣREE	94.23	106.22	137.07	110.60	128.03	106.96	222.65	122.79
LREE/HREE	5.47	8.97	11.11	8.59	13.19	8.43	9.05	11.93
(La/Yb)_N	4.25	8.63	11.10	8.09	16.25	7.35	9.11	14.75
δEu	0.95	1.12	0.72	0.93	0.75	0.91	0.58	0.90
δCe	0.75	0.72	0.75	0.72	0.71	0.74	0.75	0.74
