胶东金矿成岩成矿深度测算方法探讨

doi:10.19657/j.geoscience.1000-8527.2024.089

摘要/Abstract

摘要：

胶东金矿的储量和产量分别占全国的四分之一和三分之一。胶东地区的金矿成矿理论正经历着随地质科技发展而不断研究、讨论、发展和创新的过程。胶东西北部的新城金矿是胶东蚀变岩型金矿的典型代表,同时也是重要的生产矿山之一。随着国家对于矿产安全保障重视程度的不断提高,胶东地区深部找矿增储的迫切需求也随之而来。在矿产勘查领域,尤其是深部找矿过程中,成岩深度、成矿深度和剥蚀深度测算是重要的地质学方法。因此,本文选取新城金矿作为胶东地区的典型金矿代表,探讨其成岩、成矿和剥蚀深度的测算方法及应用。采用矿物压力计算方法,推算得到新城的成矿岩体——郭家岭花岗闪长岩的平均成岩深度为3 km;采用成矿深度构造校正方法,推算得到新城金矿的蚀变成矿平均深度为2 km;采用裂变径迹分析方法,得到新城金矿成矿后的剥蚀深度约为2.5 km。在上述成岩深度、成矿深度和剥蚀深度测算结果的基础上,深入讨论胶东地区的金矿成矿规律和深部预测问题。研究区的生产勘探工作证明,本文的成矿深度计算结果与现已认识的深部成矿规律相吻合,研究成果对胶东金矿及其他相关类型的热液金属矿床的深部找矿工作有重要的参考价值。

关键词: 成矿深度, 成岩深度, 剥蚀深度, 构造校正测算, 胶东金矿

Abstract:

The reserves and production of the Jiaodong gold deposit account for one-quarter and one-third of China’s totals, respectively.The gold mineralization theory in the Jiaodong area is continuously evolving through ongoing research, discussion, development, and innovation, driven by advances in geological science and technology.The Xincheng gold deposit in Northwestern Jiaodong is a representative example of altered-rock type gold deposits and is also one of the key production mines.With the state’s increasing attention to mineral resource safety, there is an urgent need for deep exploration and resource storage in the Jiaodong area.In the mineral exploration, particularly for deep prospecting, the estimation of diagenetic depth, metallogenic depth, and denudation depth is an important prospecting method and geological theory.Therefore, this study selects the Xincheng gold mine as a case study to discuss the methods and applications for measuring or calculating the depths of diagenesis, mineralization, and denudation.Using the Xincheng gold deposit as an example, the average diagenetic depth of the Guojialing granodiorite, the ore-host rock mass, is estimated to be 3 km based on calculated mineral formation pressure.The average depth of erosion and transformation of the Xincheng gold deposit is estimated to be 2 km using the correction method for metallogenic depth.Fission track analysis indicates that the post-mineralization denudation depth of the Xincheng gold deposit is approximately 2.5 km.Based on the above calculation results, we discuss the metallogenic patterns and predictions for gold deposit depths in the Jiaodong area.The production and exploration work in the study area has confirmed that the metal-logenic depths calculated in this study are consistent with the principles of mineralization formed in depth, providing important reference value for deep ore prospecting in the Jiaodong gold deposit and other types of hydrothermal metal deposits.

Key words: metallogenic depth, diagenetic depth, denudation depth, structural correction calculation, Jiao-dong gold deposit

中图分类号:

吕承训, 王建平, 陈小龙. 胶东金矿成岩成矿深度测算方法探讨[J]. 现代地质, 2024, 38(04): 910-921.

LÜ Chengxun, WANG Jianping, CHEN Xiaolong. Discussion on the Method for Calculating Diagenetic and Metallogenic Depths in the Jiaodong Gold Deposit[J]. Geoscience, 2024, 38(04): 910-921.

图/表 14

参考文献 32

[1]	王华东, 张建国, 宗绪臻, 等. 新城金矿床围岩蚀变与金矿化的关系[J]. 黄金学报, 1999(4):249-252.
[2]	李俊英, 郭涛, 吕古贤, 等. 新城金矿主成矿期构造应力场对矿体倾伏、侧伏、富矿柱的控制及成矿深度的估算[J]. 地学前缘, 2013, 20(4):312-319.
[3]	吕古贤, 孔庆存, 邓军, 等. 山东玲珑和焦家金矿成矿深度研究与测算[J]. 地质论评, 1996(6):550-559.
[4]	YANG L, DENG J, GUO R, et al. World-class Xincheng gold deposit: An example from the giant Jiaodong gold province[J]. Geoscience Frontiers, 2016, 7(3): 419-430.
[5]	YANG L Q, DENG J, WANG Z L, et al. Relationships between gold and pyrite at the Xincheng gold deposit, Jiaodong Peninsula, China: Implications for gold source and deposition in a brittle epizonal environment[J]. Economic Geology, 2016, 111(1): 105-126
[6]	ZHANG L, YANG L Q, WEINBERG R F, et al. Anatomy of a world-class epizonal orogenic-gold system: A holistic thermochronological analysis of the Xincheng gold deposit, Jiaodong Peninsula, eastern China[J]. Gondwana Research, 2019, 70: 50-70.
[7]	GUO L N, DENG J, YANG L Q, et al. Gold deposition and resource potential of the Linglong gold deposit, Jiaodong Peninsula: Geochemical comparison of ore fluids[J]. Ore Geology Reviews, 2020, 120: 103434.
[8]	吕古贤. 山东玲珑金矿田和焦家金矿田成矿深度的测算与研究方法[J]. 中国科学(D辑:地球科学), 1997(4):337-342.
[9]	吕古贤. 构造物理化学与金矿成矿预测[M]. 北京: 地质出版社, 1999.
[10]	ZHANG L, WEINBERG R F, YANG L Q, et al. Mesozoic orogenic gold mineralization in the Jiaodong Peninsula, China: A focused event at 120±2 Ma during cooling of pregold granite intrusions[J]. Economic Geology, 2020, 115(2): 415-441.
[11]	李士先, 刘长春, 安郁宏, 等. 胶东金矿地质[M]. 北京: 地质出版社, 2007.
[12]	DOU J Z, ZHANG H F, TONG Y, et al. 2018. Application of geothermo-barometers to Mesozoic granitoids in the Jiaodong Peninsula, eastern China: Criteria for selecting methods of pressure estimation and implications for crustal exhumation[J]. Journal of Asian Earth Sciences, 2018,160:271-286.
[13]	吕古贤, 李洪奎, 丁正江, 等. 胶东地区“岩浆核杂岩” 隆起-拆离带岩浆期后热液蚀变成矿[J]. 现代地质, 2016, 30(2): 247-262.
[14]	吕承训. 胶东金矿区域构造蚀变岩带地质特征与流体成矿规律研究[D]. 北京: 中国地质大学(北京), 2012.
[15]	任纪舜, 牛宝贵, 和政军, 等. 中国东部的构造格局和动力演化[M]// 中国地质科学院地质研究所.中国地质科学院地质研究所文集(29—30). 北京: 地质出版社, 1997:13.
[16]	YANG L Q, DILEK Y, WANG Z L, et al. Late Jurassic, high Ba-Sr Linglong granites in the Jiaodong Peninsula, east China: lower crustal melting products in the eastern North China craton[J]. Geological Magazine, 2018, 155(5): 1040-1062.
[17]	马昌前, 杨坤光, 唐仲华, 等. 华中大别山高压变质地体的形成和差异岩石隆升-剥露:来自火成岩的证据[J]. 地球科学, 1995(5):515-520.
[18]	林文蔚, 殷秀兰. 胶东金矿成矿流体同位素的地质特征[J]. 岩石矿物学杂志, 1998, 17(3): 249-259.
[19]	刘俊. 胶东西北部金矿床成岩成矿深度及变化保存研究[D]. 北京: 中国地质大学(北京), 2009.
[20]	王建平, 刘俊, 刘家军, 等. 黑云母全铝压力计估算胶东西北部玲珑花岗质杂岩剥蚀程度[J]. 矿物学报, 2009, 29(增):481-482.
[21]	RIEDER M, CAVAZZINI G, D’YAKONOV Y S, et al. Nomenclature of the micas[J]. Mineralogical Magazine, 1999, 63(2): 267-279.
[22]	ZHOU Z X. Chemical characteristics of mafic mica in intrusive rocks and its geological meaning[J]. Acta Petrology Sinica, 1988,3:63-73.
[23]	YANG K, WANG J P, LIN J Z, et al. Petrogeo-chemical characteristics and genetic significance of the Aishan pluton in the Jiaodong Peninsula[J]. Geol Expl, 2012,48:693-703.
[24]	陈小龙. 胶东新城金矿控矿构造解析及分形动力学研究[D]. 西安: 长安大学, 2010.
[25]	王仁, 黄杰藩, 孙荀英, 等. 华北地震构造应力场的模拟[J]. 中国科学(B辑化学生物学农学医学地学), 1982(4):337-344.
[26]	吕古贤, 孔庆存. 胶东玲珑—焦家式金矿地质[M]. 北京: 科学出版社, 1993.
[27]	王建平, 翟裕生, 刘家军, 等. 矿床变化与保存研究的裂变径迹新途径[J]. 地球科学进展, 2008, 23(4): 421-427. DOI
[28]	王建平, 刘俊, 刘家军, 等. 胶东西北部金矿床成岩成矿深度对比研究[J]. 矿床地质, 2010, 29(增): 997-998.
[29]	柳振江, 王建平, 郑德文, 等. 胶东西北部金矿剥蚀程度及找矿潜力和方向: 来自磷灰石裂变径迹热年代学的证据[J]. 岩石学报, 2010, 26(12): 3597-3611.
[30]	许立青, 李三忠, 郭玲莉, 等. 郯庐断裂带对鲁西隆升过程的影响: 磷灰石裂变径迹证据[J]. 岩石学报, 2016, 32(4): 1153-1170.
[31]	张玲, 杨晓平, 万景林, 等. 中新生代南北天山差异性抬升历史的磷灰石裂变径迹证据[J]. 岩石学报, 2018, 34(3): 837-850.
[32]	唐军. 华北地区古地温梯度研究与古生界油气生成[J]. 河南石油, 1998(6): 1-3, 20.

样品	SiO₂(%)	TiO₂(%)	Al₂O₃(%)	FeO(%)	MnO(%)	MgO(%)	CaO(%)	Na₂O(%)	K₂O(%)	总量(%)	Si
CJ01-1	38.17	2.20	13.85	16.80	0.07	13.36		0.06	10.13	94.65	5.804
CJ01-2	37.89	3.00	13.54	17.32	0.18	13.56			9.94	95.43	5.732
DLH01-1	38.73	1.69	13.82	17.93	0.82	12.13		0.21	10.73	96.06	5.866
DLH01-2	38.30	2.13	13.18	19.87		10.81		0.18	10.33	94.81	5.909
DZS01-1	38.54	2.64	13.53	18.89	1.27	10.52		0.25	10.19	95.83	5.877
DZS01-2	38.54	2.58	14.38	17.24	1.05	10.28		0.35	10.05	94.47	5.898
DZS01-3	38.11	2.75	13.54	19.14	1.25	10.06		0.26	10.46	95.58	5.852
GJL02-1	38.50	1.85	13.43	16.41	0.21	14.10		0.22	10.33	95.05	5.831
GJL02-2	38.36	2.02	13.15	16.87	0.12	14.31	0.09	0.15	10.00	95.07	5.813
GJL02-3	38.43	1.79	13.07	17.28	0.23	14.21	0.21		10.10	95.31	5.824
LGZ01-1	36.70	3.46	13.22	8.54	0.61	12.51			9.78	94.83	6.002
LGZ01-2	37.39	4.03	13.05	18.64	0.34	12.04			10.08	95.57	5.706
NS01-1	35.96	4.05	12.36	23.19	0.24	9.03		0.34	9.88	95.03	5.669
NS01-2	35.89	4.16	13.06	23.00	0.52	8.44		0.14	9.93	95.14	5.646
NS01-3	35.41	3.96	12.60	23.42	0.28	8.74	0.03	0.21	9.70	94.36	5.632
样品	Al^Ⅳ	Al^Ⅵ	Ti	Fe³⁺	Fe²⁺	Mn	Mg	Ca	Na	K	总量
CJ01-1	2.196	0.286	0.252	0.305	1.831	0.009	3.028	0	0.018	1.965	15.695
CJ01-2	2.268	0.146	0.341	0.321	1.870	0.023	3.058	0	0.000	1.918	15.679
DLH01-1	2.134	0.333	0.193	0.225	2.047	0.105	2.739	0	0.062	2.073	15.775
DLH01-2	2.091	0.305	0.247	0.311	2.253	0.000	2.486	0	0.054	2.033	15.689
DZS01-1	2.123	0.309	0.303	0.368	2.041	0.164	2.392	0	0.074	1.982	15.632
DZS01-2	2.102	0.491	0.297	0.458	1.748	0.136	2.345	0	0.104	1.962	15.542
DZS01-3	2.148	0.302	0.318	0.331	2.127	0.163	2.303	0	0.077	2.049	15.669
GJL02-1	2.169	0.229	0.211	0.211	1.868	0.027	3.184	0	0.065	1.996	15.789
GJL02-2	2.187	0.162	0.230	0.229	1.909	0.015	3.233	0.015	0.044	1.933	15.771
GJL02-3	2.176	0.159	0.204	0.219	1.971	0.030	3.211	0.034	0.000	1.953	15.781
LGZ01-1	1.998	0.550	0.426	0.681	0.487	0.084	3.050	0	0.000	2.040	15.319
LGZ01-2	2.294	0.053	0.463	0.361	2.018	0.044	2.739	0	0.000	1.962	15.639
NS01-1	2.296	0.000	0.480	0.252	2.805	0.032	2.122	0	0.104	1.987	15.748
NS01-2	2.354	0.067	0.492	0.331	2.695	0.069	1.979	0	0.043	1.993	15.669
NS01-3	2.362	0.000	0.474	0.270	2.845	0.038	2.072	0.005	0.065	1.968	15.730

样品	SiO₂(%)	TiO₂(%)	Al₂O₃(%)	FeO(%)	MnO(%)	MgO(%)	CaO(%)	Na₂O(%)	K₂O(%)	总量(%)	Si
CJ01-1	38.17	2.20	13.85	16.80	0.07	13.36		0.06	10.13	94.65	5.804
CJ01-2	37.89	3.00	13.54	17.32	0.18	13.56			9.94	95.43	5.732
DLH01-1	38.73	1.69	13.82	17.93	0.82	12.13		0.21	10.73	96.06	5.866
DLH01-2	38.30	2.13	13.18	19.87		10.81		0.18	10.33	94.81	5.909
DZS01-1	38.54	2.64	13.53	18.89	1.27	10.52		0.25	10.19	95.83	5.877
DZS01-2	38.54	2.58	14.38	17.24	1.05	10.28		0.35	10.05	94.47	5.898
DZS01-3	38.11	2.75	13.54	19.14	1.25	10.06		0.26	10.46	95.58	5.852
GJL02-1	38.50	1.85	13.43	16.41	0.21	14.10		0.22	10.33	95.05	5.831
GJL02-2	38.36	2.02	13.15	16.87	0.12	14.31	0.09	0.15	10.00	95.07	5.813
GJL02-3	38.43	1.79	13.07	17.28	0.23	14.21	0.21		10.10	95.31	5.824
LGZ01-1	36.70	3.46	13.22	8.54	0.61	12.51			9.78	94.83	6.002
LGZ01-2	37.39	4.03	13.05	18.64	0.34	12.04			10.08	95.57	5.706
NS01-1	35.96	4.05	12.36	23.19	0.24	9.03		0.34	9.88	95.03	5.669
NS01-2	35.89	4.16	13.06	23.00	0.52	8.44		0.14	9.93	95.14	5.646
NS01-3	35.41	3.96	12.60	23.42	0.28	8.74	0.03	0.21	9.70	94.36	5.632
样品	Al^Ⅳ	Al^Ⅵ	Ti	Fe³⁺	Fe²⁺	Mn	Mg	Ca	Na	K	总量
CJ01-1	2.196	0.286	0.252	0.305	1.831	0.009	3.028	0	0.018	1.965	15.695
CJ01-2	2.268	0.146	0.341	0.321	1.870	0.023	3.058	0	0.000	1.918	15.679
DLH01-1	2.134	0.333	0.193	0.225	2.047	0.105	2.739	0	0.062	2.073	15.775
DLH01-2	2.091	0.305	0.247	0.311	2.253	0.000	2.486	0	0.054	2.033	15.689
DZS01-1	2.123	0.309	0.303	0.368	2.041	0.164	2.392	0	0.074	1.982	15.632
DZS01-2	2.102	0.491	0.297	0.458	1.748	0.136	2.345	0	0.104	1.962	15.542
DZS01-3	2.148	0.302	0.318	0.331	2.127	0.163	2.303	0	0.077	2.049	15.669
GJL02-1	2.169	0.229	0.211	0.211	1.868	0.027	3.184	0	0.065	1.996	15.789
GJL02-2	2.187	0.162	0.230	0.229	1.909	0.015	3.233	0.015	0.044	1.933	15.771
GJL02-3	2.176	0.159	0.204	0.219	1.971	0.030	3.211	0.034	0.000	1.953	15.781
LGZ01-1	1.998	0.550	0.426	0.681	0.487	0.084	3.050	0	0.000	2.040	15.319
LGZ01-2	2.294	0.053	0.463	0.361	2.018	0.044	2.739	0	0.000	1.962	15.639
NS01-1	2.296	0.000	0.480	0.252	2.805	0.032	2.122	0	0.104	1.987	15.748
NS01-2	2.354	0.067	0.492	0.331	2.695	0.069	1.979	0	0.043	1.993	15.669
NS01-3	2.362	0.000	0.474	0.270	2.845	0.038	2.072	0.005	0.065	1.968	15.730

测试点位	^TAl (%)	压力 (kbar)	深度 (km)	^TAl 平均值	压力平均值(kb)	深度平均值(km)
CJ01-D1	2.482	0.991	3.74	2.448	0.888	3.35
CJ01-D2	2.414	0.785	2.96	2.448	0.888	3.35
DLH01-1	2.396	0.731	2.76	2.432	0.838	3.16
DLH01-D1	2.467	0.945	3.57	2.432	0.838	3.16
DZS01-1	2.432	0.838	3.16	2.492	1.020	3.85
DZS01-2	2.593	1.328	5.02
DZS01-3	2.450	0.894	3.38
GJL02-D1	2.397	0.734	2.77	2.360	0.622	2.35
GJL02-D2	2.349	0.587	2.22
GJL02-D3	2.335	0.544	2.05
LGZ01-1	2.548	1.191	4.50	2.448	0.886	3.35
LGZ01-2	2.347	0.581	2.20	2.448	0.886	3.35
NS01-1	2.296	0.428	1.62	2.360	0.620	2.34
NS01-2	2.421	0.806	3.05
NS01-3	2.362	0.626	2.36

测试点位	^TAl (%)	压力 (kbar)	深度 (km)	^TAl 平均值	压力平均值(kb)	深度平均值(km)
CJ01-D1	2.482	0.991	3.74	2.448	0.888	3.35
CJ01-D2	2.414	0.785	2.96	2.448	0.888	3.35
DLH01-1	2.396	0.731	2.76	2.432	0.838	3.16
DLH01-D1	2.467	0.945	3.57	2.432	0.838	3.16
DZS01-1	2.432	0.838	3.16	2.492	1.020	3.85
DZS01-2	2.593	1.328	5.02
DZS01-3	2.450	0.894	3.38
GJL02-D1	2.397	0.734	2.77	2.360	0.622	2.35
GJL02-D2	2.349	0.587	2.22
GJL02-D3	2.335	0.544	2.05
LGZ01-1	2.548	1.191	4.50	2.448	0.886	3.35
LGZ01-2	2.347	0.581	2.20	2.448	0.886	3.35
NS01-1	2.296	0.428	1.62	2.360	0.620	2.34
NS01-2	2.421	0.806	3.05
NS01-3	2.362	0.626	2.36

照片编号	a/c轴比值	测量颗粒数(个)
92acd	3.796	105
92bcd	2.462	109
94acd	4.253	30
95acd	3.405	40
93ac1	3.509	21
93ac2	2.418	21
均值	3.237	326
