高分辨率化学层序地层学在深水细粒沉积中的应用:以上扬子地区六塘露头五峰组—龙马溪组下段为例

doi:10.19657/j.geoscience.1000-8527.2021.01.28

现代地质 ›› 2021, Vol. 35 ›› Issue (01): 281-292.DOI: 10.19657/j.geoscience.1000-8527.2021.01.28

高分辨率化学层序地层学在深水细粒沉积中的应用:以上扬子地区六塘露头五峰组—龙马溪组下段为例

王茜¹(), 黄永建¹(), 张治锋¹, 王长红¹, 李祥¹, 刘伟²

1. 中国地质大学(北京) 地球科学与资源学院,北京 100083
2. 中国地质调查局成都地质调查中心,四川成都 610082

收稿日期:2020-07-16 修回日期:2020-08-25 出版日期:2021-02-12 发布日期:2021-03-12
通讯作者: 黄永建
作者简介:黄永建,男,副教授,1974年出生,地球化学专业,主要从事沉积学、地球化学研究。Email: haungyj@cugb.edu.cn。
王茜,女,博士研究生,1990年出生,矿产普查与勘探专业,主要从事沉积学、地球化学研究。Email: 944085175@qq.com。
基金资助:
中国地质调查局成都地质调查中心委托项目(12120115004401-04);国家科技重大专项项目(2016ZX05029-001)

Application of High-resolution Chemical Sequence Stratigraphy to Deep-water Fine-grained Sediments:A Case Study of Wufeng Formation and Lower Member of Longmaxi Formation in Liutang Outcrop, Upper Yangtze Area

WANG Qian¹(), HUANG Yongjian¹(), ZHANG Zhifeng¹, WANG Changhong¹, LI Xiang¹, LIU Wei²

1. School of Earth Sciences and Resources, China University of Geosciences, Beijing 100083,China
2. Chengdu Center, China Geological Survey, Chengdu, Sichuan 610082,China

Received:2020-07-16 Revised:2020-08-25 Online:2021-02-12 Published:2021-03-12
Contact: HUANG Yongjian

摘要/Abstract

摘要：

综合化学地层学、层序地层学的理论和方法,利用重庆石柱县六塘露头实测资料及样品分析测试资料,优选出陆源输入强度相关元素组合Al-K-Ti-Rb-Cr-Zr、自生沉淀强度相关元素组合Ca-Mn-Mg-Ba-Zn、有机质吸附及还原强度相关元素组合V-Ni-Mo-U-As作为化学层序地层划分指标体系,将六塘露头五峰组划分为LCW层序,龙马溪组下段自下而上细分为MCL1-1、MCL1-2、MCL1-3、MCL1-4层序。陆源输入强度相关主量、微量元素组合总量在层序界面附近相对较高,而在最大海泛面附近相对较低,具有元素总量减少→增加的旋回性变化特征;而自生沉淀强度相关主量元素组合总量和微量元素组合总量、有机质吸附及还原强度相关微量元素组合总量在层序界面附近一般较低,在最大海泛面附近一般较高,具元素总量增多→减少的旋回性变化特征。这种不同成因意义的元素组合总量旋回性变化是区域海平面变化的响应,具有区域一致性,可作为区域地层对比依据。

关键词: 上扬子地区, 六塘露头, 五峰组, 龙马溪组, 化学层序地层学

Abstract:

Based on the theories and methods of chemical stratigraphy and sequence stratigraphy, the data of Liutang outcrop profile and sample analysis and test in Shizhu County of Chongqing are used to optimize the indicators system for the chemical sequence stratigraphic division which are the elements assemblages of Al-K-Ti-Rb-Cr-Zr, related to input intensity of terrigenous, the elements assemblages of Ca-Mn-Mg-Ba-Zn, related to autogenetic precipitation intensity, and the elements assemblages of V-Ni-Mo-U-As related to organic matter adsorption and deoxidation intensity. The Wufeng Formation of Liutang outcrop is divided into LCW sequence, and the lower part of Longmaxi Formation is divided into MCL1-1, MCL1-2, MCL1-3, MCL1-4 sequences upwardly. The total amount of major and trace element combinations related to the input intensity of terrigenous source is relatively high near the sequence boundary, but relatively low near the most oceanic flooding surface, which has the cyclic changes characteristics of decreasing-increasing of total elements. However, the total amount of major and trace element assemblages related to autogenetic precipitation, organic matter adsorption and deoxidation intensity are generally lower near the sequence boundary and higher near the maximum flooding surface, which has the cyclic changes characteristics of increasing-decreasing the total amount of elements. The cyclic change characteristics of the total amount of element assemblages with different genetic signi-ficance is the response of regional sea level change, which has regional consistency and can be used as the basis of regional stratigraphic correlation.

Key words: Upper Yangtze area, Liutang outcrop, Wufeng Formation, Longmaxi Formation, chemical sequence stratigraphy

中图分类号:

王茜, 黄永建, 张治锋, 王长红, 李祥, 刘伟. 高分辨率化学层序地层学在深水细粒沉积中的应用:以上扬子地区六塘露头五峰组—龙马溪组下段为例[J]. 现代地质, 2021, 35(01): 281-292.

WANG Qian, HUANG Yongjian, ZHANG Zhifeng, WANG Changhong, LI Xiang, LIU Wei. Application of High-resolution Chemical Sequence Stratigraphy to Deep-water Fine-grained Sediments:A Case Study of Wufeng Formation and Lower Member of Longmaxi Formation in Liutang Outcrop, Upper Yangtze Area[J]. Geoscience, 2021, 35(01): 281-292.

图/表 9

参考文献 51

[1]	贾承造. 论非常规油气对经典石油天然气地质学理论的突破及意义[J]. 石油勘探与开发, 2017,44(1):1-11.
[2]	焦方正. 非常规油气之“非常规”再认识[J]. 石油勘探与开发, 2019,46(5):803-810.
[3]	邱振, 邹才能, 王红岩, 等. 中国南方五峰组—龙马溪组页岩气差异富集特征与控制因素[J]. 天然气地球科学, 2020,31(2):163-175.
[4]	邹才能, 董大忠, 王玉满, 等. 中国页岩气特征、挑战及前景(一)[J]. 石油勘探与开发, 2015,42(6):689-701.
[5]	QIU Z, ZOU C N. Controlling factors on the formation and distribution of “sweet-spot areas” of marine gas shales in South China and a preliminary discussion on unconventional petroleum sedimentology[J]. Journal of Asian Earth Sciences, 2020,194,103989. https://doi.org/10.1016/j.jseaes.2019.103989.
[6]	梁兴, 王高成, 徐政语, 等. 中国南方海相复杂山地页岩气储层甜点综合评价技术——以昭通国家级页岩气示范区为例[J]. 天然气工业, 2016,36(1):33-42.
[7]	马新华, 谢军. 川南地区页岩气勘探开发进展及发展前景[J]. 石油勘探与开发, 2018,45(1):161-169.
[8]	马永生, 蔡勋育, 赵培荣. 中国页岩气勘探开发理论认识与实践[J]. 石油勘探与开发, 2018,45(4):561-574.
[9]	郭旭升. 上扬子地区五峰组—龙马溪组页岩层序地层及演化模式[J]. 地球科学, 2017,42(7):1069-1082.
[10]	陆扬博, 马义权, 王雨轩, 等. 上扬子地区五峰组—龙马溪组主要地质事件及岩相沉积响应[J]. 地球科学, 2017,42(7):1169-1184.
[11]	王玉满, 李新景, 董大忠, 等. 上扬子地区五峰组—龙马溪组优质页岩沉积主控因素[J]. 天然气工业, 2017,37(4):9-20.
[12]	ABOUELRESH M O, SLATT R M. Lithofacies and sequence stratigraphy of the Barnett shale in East-Central Fort Worth Basin, Texas[J]. AAPG Bulletin, 2012,96(1):1-22.
[13]	HAMMES U, FRÉBOURG G. Haynesville and Bossier mudrocks: A facies and sequence stratigraphic investigation, East Texas and Louisiana, USA[J]. Marine and Petroleum Geology, 2012,31(1):8-26.
[14]	LASH G G, ENGELDER T. Thickness trends and sequence stratigraphy of the Middle Devonian Marcellu Formation, Appalachian Basin: Implications for Acadian foreland basin evolution[J]. AAPG Bulletin, 2011,95(1):61-103.
[15]	SLATT R M, RODRIGUEZ N D. Comparative sequence stratigraphy and organic geochemistry of gas shales: Commonality or coincidence?[J]. Journal of Natural Gas Science and Engineering, 2012,8:68-84.
[16]	TURNER B W, MOLINARES-BLANCO C E, SLATT R M. Chemostratigraphic, palynostratigraphic, and sequence stratigraphic analysis of the Woodford Shale,Wyche Farm Quarry, Pontotoc County, Oklahoma[J]. Interpretation, 2015,3(1):1-9.
[17]	PAN S Q, ZOU C N, YANG Z, et al. Methods for shale gas play assessment: A comparison between Silurian Longmaxi shale and Mississippian Barnett shale[J]. Journal of Earth Science, 2015,26(2):285-294.
[18]	李一凡, 樊太亮, 高志前, 等. 渝东南地区志留系黑色页岩层序地层研究[J]. 天然气地球科学, 2012,23(2):299-306.
[19]	CHEN L, LU Y C, JIANG S, et al. Heterogeneity of the Lower Silurian Longmaxi marine shale in the Southeast Sichuan Basin of China[J]. Marine and Petroleum Geology, 2015,65:232-246.
[20]	WANG Y M, DONG D Z, LI X J, et al. Stratigraphic sequence and sedimentary characteristics of Lower Silurian Longmaxi Formation in Sichuan Basin and its peripheral areas[J]. Natural Gas Industry B, 2015,2(2/3):222-232.
[21]	王同, 杨克明, 熊亮, 等. 川南地区五峰组—龙马溪组页岩层序地层及其对储层的控制[J]. 石油学报, 2015,36(8):915-925.
[22]	HAQ B U, HARDENBOL J, VAIL P R. Mesozoic and Cenozoic chronostratigraphy and cycles of sea-level change[M] //WILGUS C K, HASTINGS B S, KENDALL C, et al. Sea Level Changes—An Integrated Approach. New York: Society of Economic Paleontologists and Mineralogists (SEPM), Special Publication, 1988,42:71-108.
[23]	HAQ B U, SCHUTTER S R. A chronology of Paleozoic sea-level changes[J]. Science, 2008,322:64-68. DOI URL PMID
[24]	POSAMENTIER H W, VAIL P R. Eustatic controls on clastic deposition II — sequence and systems tract models[M] //WILGUS C K, HASTINGS B S, KENDALL C, et al. Sea Level Changes — An Integrated Approach. New York: Society of Economic Paleontologists and Mineralogists (SEPM), Special Publication, 1988,42:125-154.
[25]	CATUNEANU O, ABREU V, BHATTACHARYA J P, et al. Towards the standardization of sequence stratigraphy[J]. Earth-Science Reviews, 2009,92(1/2):1-33.
[26]	ZHAI G, LI J, JIAO Y, et al. Applications of chemostratigraphy in a characterization of shale gas sedimentary microfacies and predictions of sweet spots —taking the Cambrian black shales in Western Hubei as an example[J]. Marine and Petroleum Geology, 2019,109:547-560.
[27]	MARTÍN-FERNÁNDEZ J A, BARCELÓ-VIDAL C, PAWLOWSKY-GLAHN V, et al. Subcompositional patterns in Cenozoic volcanic rocks of Hungary[J]. Mathematical Geology , 2005,37(7):729-752.
[28]	MARTIN-FERNANDEZ J A, BARCELO-VIDAL C, PAWLOWSKY-GLAHN V. Dealing with zeros and missing values in compositional data sets using nonparametric imputation[J]. Mathematical Geology, 2003,35(3):253-278.
[29]	PALAREA-ALBALADEJO J, MARTÍN-FERNÁNDEZ J A, GÓMEZ-GARCÍA J. A parametric approach for dealing with compositional rounded zeros[J]. Mathematical Geology, 2007,39(7):625-645.
[30]	PALAREA-ALBALADEJO J MARTÍN-FERNÁNDEZ J A. A modified EM alr-algorithm for replacing rounded zeros in compositional data sets[J]. Computers & Geosciences, 2008,34:902-917.
[31]	SANDFORD R F, PIERSON C T, CROVELLI R A. An objective replacement method for censored geochemical data[J]. Mathematical Geology, 1993,25(1):59-80.
[32]	PISON G, ROUSSEEUW P, FILZMOSER P, et al. Robust factor analysis[J]. Journal of Multivariate Analysis, 2003,84:145-172.
[33]	FILZMOSER P, HRON K. Outlier detection for compositional data using robust methods[J]. Mathematical Geosciences, 2008,40(3):233-248.
[34]	REIMAN C, FILMOSER P. Normal and lognormal data distribution in geochemistry: death of a myth. Consequences for the statistical treatment of geochemical and environmental data[J]. Environmental Geology, 1999,39:1001-1014.
[35]	程文斌, 顾雪祥, 胡修棉, 等. 现代大洋红色黏土与白垩纪大洋红层元素地球化学对比[J]. 地质学报, 2008,82(1):37-47.
[36]	李关清, 程文斌, 章永梅, 等. 藏南扎西康Sb-Pb-Zn-Ag多金属矿集区下侏罗统日当组赋矿地层元素地球化学特征及地质意义[J]. 矿物岩石地球化学通报, 2014,33(5):598-608.
[37]	PEARCE T J, MARTIN J H, COOPER D, et al. Chemostratigraphy of Upper Carboniferous (Pennsylvanian) sequences from the southern North Sea (United Kingdom)[M] //RATCLIFFE K T, ZAITLIN B A. Modern Alternative Stratigraphic Techniques, Theory and Case Histories. New York: SEPM Special Publication No.94, 2010: 109-129.
[38]	SANO J L, RATCLIFFE K T, SPAIN D. Chemostratigraphy of the Haynesville Shale[J]. AAPG Memoir, 2013,105:137-154.
[39]	RATCLIFFE K T, WILSON A, PAYENBERG T, et al. Ground trothing chemostratigraphic correlations in fluvial systems[J]. AAPG Bulletin, 2015,99:155-180.
[40]	CRAIGIE N. Principles of Elemental Chemostratigraphy: A Practical User Guide[M]. Heverlee: Springer, 2018: 1-177.
[41]	CALVERT S E, PEDERSEN T F. Geochemistry of recent oxic and anoxic sediments: implications for the geological record[J]. Marine Geology, 1993,113:67-88.
[42]	TURGEON S, BRUMSACK H J. Anoxic vs dysoxic events reflected in sediment geochemistry during the Cenomanian-Turonian Boundary Event(Cretaceous)in the Umbria-Marche Basin of central Italy[J]. Chemical Geology, 2006,234:321-339.
[43]	WEDEPOHL K H. The composition of the upper Earth’s crust and the natural cycles of selected metals[M] // MERIAN E. Metals and Their Compounds in the Environment. Weinheim: VCH-Verlags Gesellschaft, 1991: 3-17.
[44]	LI Y H, SCHOONMAKER J E. Chemical composition and minera-logy of marine sediments[M] //RUDNICK R L. Treatise on Geochemistry, Sediments, Diagenesis, and Sedimentary Rocks. New York: Elsevier Sciences, 2003: 1-35.
[45]	TRIBOVILLARD N, ALGEO T J, LYONS T, et al. Trace metals as paleoredox and paleoproductivity proxies: an update[J]. Chemical Geology , 2006,232:12-32.
[46]	RAMKUMAR M. Chemostratigraphy:Concepts,Techniques, and Applications[M]. New York: Elsevier, 2015: 1-432.
[47]	林畅松, 张燕梅, 刘景彦, 等. 高精度层序地层学和储层预测[J]. 地学前缘, 2000,7(3):111-117.
[48]	郑荣才, 文华国, 李凤杰. 高分辨率层序地层学[M]. 北京: 地质出版社, 2010: 1-404.
[49]	辛仁臣, 王树恒, 梁江平, 等. 松辽盆地北部西斜坡青山口组三段四级层序格架内沉积微相分布[J]. 现代地质, 2014,28(4):782-790,798.
[50]	谭聪, 于炳松, 阮壮, 等. 四川盆地上三叠统须家河组高分辨率层序地层研究[J]. 现代地质, 2017,31(2):290-301.
[51]	李杨, 阮壮, 李中明, 等. 南华北地区及其北部邻区上石炭统—中二叠统高分辨率层序地层[J]. 现代地质, 2020,34(4):718-731.

元素(氧化物)	石英	方解石	白云石	伊利石	微斜长石	斜长石	黄铁矿	绿泥石
SiO₂	0.841	-0.766	-0.997	-0.480	-0.240	-0.116	-0.192	-0.407
Al₂O₃	-0.700	0.720	-0.923	0.859	0.342	0.350	-0.239	0.244
Fe₂O₃	-0.731	0.845	0.295	0.577	0.157	0.078	0.165	0.504
CaO	-0.316	0.975	0.995	-0.274	0.024	-0.134	0.037	0.233
MgO	-0.731	0.405	0.998	0.267	0.200	-0.028	-0.212	0.552
K₂O	-0.647	-0.755	-0.947	0.861	0.300	0.314	-0.184	0.205
Na₂O	-0.446	0.268	-0.984	0.190	0.724	0.850	-0.132	-0.136
MnO	-0.321	0.710	0.972	-0.194	-0.043	-0.163	0.107	0.265
TiO₂	-0.660	0.694	-0.934	0.736	0.519	0.566	-0.242	0.046
P₂O₅	-0.265	0.878	0.873	0.037	0.172	0.253	0.438	-0.035
V	0.448	-0.583	-0.129	-0.285	-0.377	-0.345	0.118	-0.151
Cr	0.033	0.893	-0.854	0.199	-0.279	-0.174	-0.048	-0.096
Co	-0.001	-0.461	0.741	-0.204	0.257	0.093	0.334	0.089
Ni	0.112	-0.177	0.500	-0.141	-0.106	-0.091	0.290	-0.028
Zn	-0.398	0.796	-0.756	0.373	0.283	0.205	-0.269	0.180
Cu	0.373	0.135	0.999	-0.313	-0.439	-0.380	0.707	-0.035
Ba	-0.451	0.939	-0.367	0.402	0.208	0.094	-0.143	0.215
La	-0.056	0.282	-0.866	0.382	0.012	0.012	-0.257	0.049
Ce	0.062	0.497	-0.735	0.194	-0.088	-0.030	0.051	-0.095
Zr	-0.207	0.348	-1.000	0.103	0.611	0.664	-0.372	-0.347
Rb	-0.362	0.918	-0.951	0.621	0.096	0.023	-0.112	0.027
As	0.120	0.980	0.741	-0.176	0.118	0.214	0.436	-0.239
Th	-0.193	0.696	-0.866	0.330	0.012	0.085	-0.064	0.053
U	0.163	-0.333	0.010	-0.076	-0.104	-0.085	0.262	0.029
Mo	0.225	0.010	0.010	-0.114	-0.162	-0.127	0.414	0.000

元素(氧化物)	石英	方解石	白云石	伊利石	微斜长石	斜长石	黄铁矿	绿泥石
SiO₂	0.841	-0.766	-0.997	-0.480	-0.240	-0.116	-0.192	-0.407
Al₂O₃	-0.700	0.720	-0.923	0.859	0.342	0.350	-0.239	0.244
Fe₂O₃	-0.731	0.845	0.295	0.577	0.157	0.078	0.165	0.504
CaO	-0.316	0.975	0.995	-0.274	0.024	-0.134	0.037	0.233
MgO	-0.731	0.405	0.998	0.267	0.200	-0.028	-0.212	0.552
K₂O	-0.647	-0.755	-0.947	0.861	0.300	0.314	-0.184	0.205
Na₂O	-0.446	0.268	-0.984	0.190	0.724	0.850	-0.132	-0.136
MnO	-0.321	0.710	0.972	-0.194	-0.043	-0.163	0.107	0.265
TiO₂	-0.660	0.694	-0.934	0.736	0.519	0.566	-0.242	0.046
P₂O₅	-0.265	0.878	0.873	0.037	0.172	0.253	0.438	-0.035
V	0.448	-0.583	-0.129	-0.285	-0.377	-0.345	0.118	-0.151
Cr	0.033	0.893	-0.854	0.199	-0.279	-0.174	-0.048	-0.096
Co	-0.001	-0.461	0.741	-0.204	0.257	0.093	0.334	0.089
Ni	0.112	-0.177	0.500	-0.141	-0.106	-0.091	0.290	-0.028
Zn	-0.398	0.796	-0.756	0.373	0.283	0.205	-0.269	0.180
Cu	0.373	0.135	0.999	-0.313	-0.439	-0.380	0.707	-0.035
Ba	-0.451	0.939	-0.367	0.402	0.208	0.094	-0.143	0.215
La	-0.056	0.282	-0.866	0.382	0.012	0.012	-0.257	0.049
Ce	0.062	0.497	-0.735	0.194	-0.088	-0.030	0.051	-0.095
Zr	-0.207	0.348	-1.000	0.103	0.611	0.664	-0.372	-0.347
Rb	-0.362	0.918	-0.951	0.621	0.096	0.023	-0.112	0.027
As	0.120	0.980	0.741	-0.176	0.118	0.214	0.436	-0.239
Th	-0.193	0.696	-0.866	0.330	0.012	0.085	-0.064	0.053
U	0.163	-0.333	0.010	-0.076	-0.104	-0.085	0.262	0.029
Mo	0.225	0.010	0.010	-0.114	-0.162	-0.127	0.414	0.000

元素	相关矿物	主要成因意义
Si	石英,其他硅酸盐	陆源或自生
Al、Ga	主要是黏土矿物,少量与长石有关	陆源
K、Rb	钾长石、云母和黏土矿物(特别是伊利石)	陆源
Cs、Sc	黏土矿物和长石	陆源
V	主要是黏土矿物,V在缺氧条件下吸附在黏土矿物上	还原
Ca	主要是方解石和白云石,也与石膏和硬石膏有关,少量与蒙脱石和斜长石有关	自生为主
Mg	主要是白云石、方解石和/或黏土矿物(尤其是绿泥石)	自生为主
Fe、Mn	各种黏土和碳酸盐矿物以及黄铁矿	陆源或自生
Na	主要是斜长石,但有些钠与石盐和/或黏土矿物(如蒙脱石)有关	陆源或自生
Ti、Ta、Nb	钛磁铁矿、磁铁矿、钛铁矿、金红石、锐钛矿和/或闪锌矿	陆源
Th	重矿物,特别是独居石、锆石和磷灰石	陆源
REE	轻稀土元素在黏土矿物和长石中最为丰富,而重稀土元素存在于重矿物中	陆源
U	重矿物和有机物,还原环境	陆源或还原
Cr	重矿物,如铬尖晶石	陆源
Zr、Hf	锆石	陆源
P	生物磷、含磷重矿物(磷灰石和独居石),少量磷与碳酸盐和黏土矿物有关	自生
Zn、Ni、Mo、Co、Cu	黄铁矿、氢氧化铁、碳酸盐和/或黏土矿物	自生或陆源
Ba	碳酸盐,如重晶石	自生
Sr	长石、黏土矿物、碳酸盐	陆源或自生

元素	相关矿物	主要成因意义
Si	石英,其他硅酸盐	陆源或自生
Al、Ga	主要是黏土矿物,少量与长石有关	陆源
K、Rb	钾长石、云母和黏土矿物(特别是伊利石)	陆源
Cs、Sc	黏土矿物和长石	陆源
V	主要是黏土矿物,V在缺氧条件下吸附在黏土矿物上	还原
Ca	主要是方解石和白云石,也与石膏和硬石膏有关,少量与蒙脱石和斜长石有关	自生为主
Mg	主要是白云石、方解石和/或黏土矿物(尤其是绿泥石)	自生为主
Fe、Mn	各种黏土和碳酸盐矿物以及黄铁矿	陆源或自生
Na	主要是斜长石,但有些钠与石盐和/或黏土矿物(如蒙脱石)有关	陆源或自生
Ti、Ta、Nb	钛磁铁矿、磁铁矿、钛铁矿、金红石、锐钛矿和/或闪锌矿	陆源
Th	重矿物,特别是独居石、锆石和磷灰石	陆源
REE	轻稀土元素在黏土矿物和长石中最为丰富,而重稀土元素存在于重矿物中	陆源
U	重矿物和有机物,还原环境	陆源或还原
Cr	重矿物,如铬尖晶石	陆源
Zr、Hf	锆石	陆源
P	生物磷、含磷重矿物(磷灰石和独居石),少量磷与碳酸盐和黏土矿物有关	自生
Zn、Ni、Mo、Co、Cu	黄铁矿、氢氧化铁、碳酸盐和/或黏土矿物	自生或陆源
Ba	碳酸盐,如重晶石	自生
Sr	长石、黏土矿物、碳酸盐	陆源或自生

元素 (氧化物)	SiO₂	Al₂O₃	Fe₂O₃	CaO	MgO	K₂O	Na₂O	MnO	TiO₂	P₂O₅	V	Cr	Co	Ni	Zn	Cu	Ba	La	Ce	Zr	Rb	As	Th	U	Mo
SiO₂	1.00
Al₂O₃	-0.66	1.00
Fe₂O₃	-0.73	0.52	1.00
CaO	-0.43	-0.23	0.15	1.00
MgO	-0.82	0.53	0.68	0.59	1.00
K₂O	-0.64	0.96	0.44	-0.24	0.44	1.00
Na₂O	-0.04	0.23	0.04	-0.09	0.10	0.10	1.00
MnO	-0.43	-0.15	0.30	0.83	0.61	-0.23	0.05	1.00
TiO₂	-0.59	0.88	0.35	-0.20	0.37	0.91	0.25	-0.25	1.00
P₂O₅	-0.30	0.01	0.39	0.14	0.17	-0.04	0.37	0.27	0.07	1.00
V	0.17	-0.39	-0.17	-0.04	-0.35	-0.23	-0.47	-0.16	-0.23	-0.08	1.00
Cr	-0.33	0.49	0.20	-0.19	0.16	0.54	-0.19	-0.24	0.52	-0.07	0.16	1.00
Co	0.11	-0.25	0.17	0.09	0.02	-0.33	0.22	0.26	-0.41	0.15	-0.10	-0.30	1.00
Ni	-0.08	-0.29	0.28	0.10	-0.14	-0.20	-0.21	0.04	-0.17	0.31	0.61	0.05	0.14	1.00
Zn	-0.35	0.35	0.61	-0.05	0.33	0.31	0.19	0.02	0.34	0.26	-0.04	0.22	0.06	0.35	1.00
Cu	0.07	-0.23	-0.02	0.04	-0.12	-0.22	-0.38	0.03	-0.24	0	0.23	0.23	-0.07	0.24	-0.13	1.00
Ba	-0.51	0.60	0.39	-0.08	0.39	0.64	0.05	-0.10	0.62	-0.05	-0.03	0.43	-0.22	-0.03	0.38	-0.14	1.00
La	-0.08	0.30	0.08	-0.33	-0.05	0.31	-0.01	-0.27	0.24	-0.09	0.00	0.33	-0.13	0.03	0.20	0	0.21	1.00
Ce	-0.10	0.29	-0.07	-0.18	-0.03	0.32	-0.12	-0.20	0.29	-0.17	0.04	0.49	-0.23	-0.12	-0.05	0.06	0.11	0.13	1.00
Zr	-0.12	0.40	-0.05	-0.16	0.02	0.39	0.56	-0.22	0.61	0.07	-0.26	0.14	-0.23	-0.18	0.16	-0.27	0.29	0.09	0.11	1.00
Rb	-0.53	0.81	0.35	-0.23	0.34	0.85	-0.01	-0.23	0.77	-0.13	-0.14	0.53	-0.39	-0.17	0.29	-0.08	0.62	0.29	0.37	0.35	1.00
As	-0.14	0.03	-0.05	-0.03	-0.15	0.16	0.01	-0.15	0.26	0.14	0.25	0.20	-0.14	0.28	0.06	0.06	0.23	0.03	0.14	0.27	0.19	1.00
Th	-0.19	0.32	0.02	-0.09	0.09	0.36	0.05	-0.15	0.36	-0.08	-0.06	0.25	-0.18	-0.14	0.05	-0.04	0.19	0.14	0.29	0.21	0.35	0.11	1.00
U	0.01	-0.23	0.03	-0.06	-0.25	-0.13	-0.19	-0.07	-0.14	0.16	0.56	0.00	0.03	0.57	0.04	0.14	-0.02	0.05	-0.06	-0.09	-0.01	0.24	-0.04	1.00
Mo	0.14	-0.39	-0.19	-0.02	-0.37	-0.28	-0.28	-0.06	-0.31	-0.06	0.59	-0.13	0.04	0.41	-0.17	0.13	-0.17	0.02	0	-0.21	-0.22	0.23	-0.09	0.46	1.00

高分辨率化学层序地层学在深水细粒沉积中的应用:以上扬子地区六塘露头五峰组—龙马溪组下段为例

Application of High-resolution Chemical Sequence Stratigraphy to Deep-water Fine-grained Sediments:A Case Study of Wufeng Formation and Lower Member of Longmaxi Formation in Liutang Outcrop, Upper Yangtze Area

RichHTML

PDF (PC)

可视化

摘要/Abstract

引用本文

使用本文

图/表 9

参考文献 51

相关文章 10

编辑推荐

Metrics

本文评价

主量元素 (氧化物)	主成分1	主成分2	主成分3	主成分4	主成分5
SiO₂	-0.920	-0.243	0.111	0.083	0.131
Al₂O₃	0.859	-0.465	-0.053	0.092	0.071
Fe₂O₃	0.760	0.203	0.061	-0.467	0.360
CaO	0.205	0.877	-0.195	0.247	-0.215
MgO	0.817	0.444	-0.158	0.135	0.160
K₂O	0.815	-0.525	-0.151	0.052	-0.093
Na₂O	0.213	-0.079	0.806	0.501	0.198
MnO	0.261	0.899	-0.014	0.168	0.042
TiO₂	0.775	-0.516	0.023	0.143	-0.254
P₂O₅	0.276	0.320	0.748	-0.405	-0.290

微量元素	主成分1	主成分2	主成分3	主成分4	主成分5
V	-0.337	0.787	-0.122	-0.024	0.032
Cr	0.662	0.431	-0.246	0.365	-0.088
Co	-0.459	-0.205	0.368	0.214	0.220
Ni	-0.361	0.733	0.334	0.155	-0.089
Zn	0.310	0.213	0.707	0.359	-0.063
Cu	-0.173	0.334	-0.459	0.420	-0.442
Ba	0.675	0.244	0.335	0.047	-0.135
La	0.363	0.230	0.058	0.318	0.587
Ce	0.458	0.205	-0.516	0.005	0.159
Zr	0.565	-0.055	0.262	-0.507	-0.080
Rb	0.835	0.211	0.024	0.009	-0.020
As	0.167	0.529	0.097	-0.515	-0.265
Th	0.479	0.097	-0.203	-0.169	0.339
U	-0.308	0.698	0.142	-0.142	0.129
Mo	-0.454	0.582	-0.129	-0.261	0.287

层序及关键界面	陆源输入指标元素		自生沉淀指标元素		有机质吸附强度指标元素
层序及关键界面	Al+K+Ti/ %	Cr+Zr+Rb/ 10^-6	(Ca+Mg+Mn)/Al /%	(Zn+Ba)/Al /10^-6	V+Ni+Mo+U+As /10^-6	EF(V+Ni+Mo+ U+As)
SBL2	22.33	329.00	10	9 495	155.40	3.05
mfsL1-4	17.20	260.00	16	20 632	316.67	106.33
SBL1-4	19.42	343.00	14	14 203	126.83	3.56
MCL1-4(均值)	21.19	342.31	16	13 182	188.90	7.43
mfsL1-3	18.01	319.00	32	17 131	151.46	6.91
SBL1-3	23.49	450.00	9	8 739	123.39	4.30
MCL1-3(均值)	19.08	349.20	16	11 201	153.43	8.14
mfsL1-2	15.41	284.00	13	13 664	255.10	8.29
SBL1-2	22.68	412.00	9	10 164	122.30	3.34
MCL1-2(均值)	18.40	343.15	10	11 256	190.66	22.62
mfsL1-1	8.57	146.00	23	14 356	556.60	597.51
SBL1	16.41	349.00	10	10 607	135.07	282.28
MCL1-1(均值)	15.64	293.33	19	10 682	314.72	110.68
mfsW	3.71	110.00	11	14 447	494.40	339.39
SBW	22.17	359.00	10	5 790	76.70	3.53
LCW(均值)	11.82	219.64	35	9 383	304.26	96.08

[1]	李东升, 高平, 盖海峰, 刘若冰, 蔡益栋, 李刚, 周秦, 肖贤明. 川东南地区龙马溪组页岩有机质纳米孔隙结构表征[J]. 现代地质, 2023, 37(05): 1293-1305.
[2]	漆洋, 吕春研, 王宇慧, 唐书恒, 郗兆栋. 生物地层格架下湘西北地区五峰组—龙马溪组孔隙结构特征[J]. 现代地质, 2022, 36(05): 1292-1303.
[3]	黄莫, 李明, 杨振京, 邓丽婷. 湖南益阳奥陶系五峰组—志留系周家溪群笔石[J]. 现代地质, 2021, 35(05): 1343-1353.
[4]	饶权, 康永尚, 黄毅, 赵群, 王红岩. 蜀南地区龙马溪组页岩气工业建产区游离气和孔隙度下限讨论[J]. 现代地质, 2021, 35(04): 1054-1064.
[5]	蔺东林, 唐书恒, 郗兆栋, 张松航, 周淑林. 湘西北ZY3井五峰组页岩地球化学特征与有机质富集控制因素[J]. 现代地质, 2020, 34(06): 1144-1152.
[6]	黄宇琪, 张鹏, 张金川, 杨军伟. 湖北来凤LD-1井龙马溪组页岩孔隙结构特征分析[J]. 现代地质, 2020, 34(04): 828-836.
[7]	王朋飞, 姜振学, 金璨, 吕鹏, 李鑫, 张昆, 王凯, 黄璞. 渝东南下志留统龙马溪组页岩有机质孔隙发育特征:基于聚焦离子束氦离子显微镜(FIB-HIM)技术[J]. 现代地质, 2019, 33(04): 902-910.
[8]	王子轶, 高志前, 石文睿, 王兴志, 赵红燕. 四川盆地五峰组—龙马溪组笔石与页岩气关系探讨[J]. 现代地质, 2019, 33(02): 379-388.
[9]	李娟, 于炳松, 刘策, 孙梦迪. 渝东南地区黑色页岩中粘土矿物特征兼论其对储层物性的影响——以彭水县鹿角剖面为例[J]. 现代地质, 2012, 26(4): 732-740.
[10]	久凯, 丁文龙, 黄文辉, 张金川, 曾维特. 上扬子地区下寒武统海相富有机质页岩形成环境与主控因素分析[J]. 现代地质, 2012, 26(3): 547-554.
