地下水中镭的固液分配系数及其测定方法研究

doi:10.19657/j.geoscience.1000-8527.2022.007

摘要/Abstract

摘要：

近十多年来天然放射性镭(Ra)同位素在水环境、水资源研究领域越来越受到重视,Ra同位素应用在海底地下水排泄估算、湖泊水均衡计算、地下水年龄研究、地下水地表水污染源解析等方面取得了重要的研究成果,这得益于Ra同位素测试技术的发展和对Ra地球化学性质认识的深化。Ra的固液分配系数(K_d)是影响Ra在土壤和含水层中迁移的关键参数,正确认识K_d是利用Ra同位素精准示踪水文过程特别是地下水循环过程的决定性因素。本研究对前人报道的地下水中Ra的K_d值分布范围进行了综合分析,并探讨K_d值的主要影响因素。发现天然环境下K_d值的变化范围为0.1~1×10⁶ mL·g^-1,最大值和最小值之间相差7个数量级。水的盐度、pH值和沉积物中铁(Fe)的含量等对K_d具有显著影响。总结了Ra的K_d值的确定方法,把不同研究者提出的方法归纳为氡(Rn)平衡法、热动力学吸附平衡计算法、实验法和离子交换法,分析了各种方法的优缺点。提出建立精准的水溶液中Ra的α离子输入反冲项测定方法,优化分析计算流程,提供准确获得Ra的K_d值的技术思路。本研究成果能够为Ra水文地球化学性质研究及其在水文过程中的应用提供参考和技术支撑。

关键词: 分配系数, Ra同位素, α离子输入反冲项

Abstract:

In the past decade, the Ra isotope has attracted increasingly more research attention in the field of water environment and water resources. Important findings have been made on the application of Ra isotopes in estimating seabed groundwater discharge, calculating lake water balance, study of groundwater age and analysis of groundwater pollution source. This is due to the development of Ra isotope analytical technology and the enhanced understanding of Ra geochemical behavior. The Ra distribution coefficient (K_d) is a key parameter affecting the Ra migration in soil and aquifer, and its understanding is pivotal for accurate tracing of hydrological processes, especially groundwater cycle. We compiled a range of K_d value and analyzed the main influencing factors. We found that the K_d value in natural environment varies from 0.1-1×10⁶ mL·g^-1, extending across seven orders of magnitude between the maximum and minimum. The water salinity, pH, and Fe content in sediments have significant impact on K_d. The K_d determination methods were summarized and divided into four types, including the (1) “Rn” equilibrium, (2) thermodynamic adsorption equilibrium calculation, (3) experimental method, and (4) ion exchange equilibrium method. The pros and cons of each method were analyzed. We proposed the establishment of an accurate determination method of ion input recoil term in aqueous solution and to optimize analysis and calculation process, which is the technical idea of obtaining K_dvalue accurately. Our review and analysis can provide reference and technical support for studying the hydrogeochemical properties of Ra and its hydrologic applications.

Key words: distribution coefficient, radium, α-recoiled radium ion

中图分类号:

P641.3

郝鑫, 易立新, 李璐旋, 杨永鹏. 地下水中镭的固液分配系数及其测定方法研究[J]. 现代地质, 2022, 36(02): 552-562.

HAO Xin, YI Lixin, LI Luxuan, YANG Yongpeng. Distribution Coefficient of Ra in Groundwater and Its Determination Technique[J]. Geoscience, 2022, 36(02): 552-562.

图/表 5

参考文献 63

[1]	ERKAN K, HASAN B. Sediment distribution coefficients (K_d) and bioaccumulation factors (BAF) in biota for natural radionuclides in eastern Black Sea coast of Turkey[J]. Microchemical Journal, 2019, 149:104044.
[2]	CIFFROY P, DURRIEU G, GARNIER J M. Probabilistic distribution coefficients (K_ds) in freshwater for radioisotopes of Ag, Am, Ba, Be, Ce, Co, Cs, I, Mn, Pu, Ra, Ru, Sb, Sr and Th-implications for uncertainty analysis of models simulating the transport of radionuclides in rivers[J]. Journal of Environmental Radioactivity, 2008, 100(9): 785-794.
[3]	CHEN Z. A case against K_d-based transport models: natural attenuation at a mill tailings site[J]. Computers and Geosciences, 2003, 29(3): 351-359.
[4]	刘花台, 郭占荣, 袁晓婕, 等. 用镭同位素评价海水滞留时间及海底地下水排泄[J]. 地球科学--中国地质大学学报, 2013, 38(3):599-606.
[5]	郭占荣, 黄磊, 袁晓婕, 等. 用镭同位素评价九龙江河口区的地下水输入[J]. 水科学进展, 2011, 122(1):118-125.
[6]	杨英魁, 何炳毅, 孔凡翠, 等. 镭同位素示踪盐湖地下水排放通量--以大柴旦盐湖为例[J]. 地质学报, 2021, 95(7):2238-2248.
[7]	KIRO Y, WEINSTEIN Y, STARINSKY A, et al. Application of radon and radium isotopes to groundwater flow dynamics: An example from the Dead Sea[J]. Chemical Geology, 2015, 411:155-171.
[8]	LUO X, JIAO J, WANG X, et al. Groundwater discharge and hydrologic partition of the lakes in desert environment: Insights from stable ¹⁸O/²H and radium isotopes[J]. Journal of Hydrology, 2017, 546:189-203
[9]	DULAIOVA H, BURNETT C W. Evaluation of the flushing rates of Apalachicola Bay, Florida via natural geochemical tra-cers[J]. Marine Chemistry, 2007, 109(3): 395-408.
[10]	PETERSON N R, BURNETT C W, MAKOTO T, et al. Determination of transport rates in the Yellow River-Bohai Sea mixing zone via natural geochemical tracers[J]. Continental Shelf Research, 2008, 28(19): 2700-2707.
[11]	MORRE S W, JOSELENSE D O. Determination of residence time and mixing processes of the Ubatuba, Brazil, inner shelf waters using natural Ra isotopes[J]. Estuarine, Coastal and Shelf Science, 2007, 76(3): 512-521.
[12]	MORRE S W. Ages of continental shelf waters determined from ²²³Ra and ²²⁴Ra[J]. Journal of Geophysical Research:Oceans, 2000, 105(9): 22117-22122.
[13]	KIRO Y, YECHIELI Y, VOSS I C, et al. Modeling radium distribution in coastal aquifers during sea level changes: The Dead Sea case[J]. Geochimica et Cosmochimica Acta, 2012, 88: 237-254.
[14]	RAM A, MORRE S W. Using the radium quartet for evaluating groundwater input and water exchange in salt marshes[J]. Geochimica et Cosmochimica Acta, 1996, 60: 4645-4652.
[15]	袁晓婕, 郭占荣, 刘洁, 等. 咸水环境下沉积物中镭的解吸特点[J]. 地球学报, 2014, 35(5):582-588.
[16]	BECK J A, COCHRAN A M. Controls on solid-solution partitioning of radium in saturated marine sands[J]. Marine Chemistry, 2013, 156: 38-48.
[17]	VANDENHOVE H, VAN H M, WOUTERS K, et al. Can we predict uranium bioavailability based on soil parameters? Part 1: effect of soil parameters on soil solution uranium concentration[J]. Environmental Pollution, 2007, 145(2): 587-595.
[18]	RODRIGUEZ B P, LOZANO C J, TOME V, et al. Influence of soil conditions on the distribution coefficients of ²²⁶Ra in natural soils[J]. Chemosphere, 2018, 205: 188-193.
[19]	WEAVER T R, BAHR J. Geochemical evolution in the Cam-brian-Ordovician sandstone aquifer, eastern Wisconsin: 1. Major ion and radionuclide distribution[J]. Groundwater, 1991, 29(3): 350-356.
[20]	GONNEEA E M, MORRIS J P, DULAIOVA H, et al. New perspectives on radium behavior within a subterranean estuary[J]. Marine Chemistry, 2007, 109(3): 250-267.
[21]	CABLE E J, SMITH G C, BLANFIRD J W. Dispersivity and distribution coefficients in marine sediments using ³H and ²²⁶Ra[J]. Radioprotection, 2009, 44(5): 185-190.
[22]	LIU Y, JIAO J J, MAO R, et al. Spatial characteristics reveal the reactive transport of radium isotopes (²²⁴Ra, ²²³Ra, and ²²⁸Ra) in an intertidal aquifer[J]. Water Resources Research, 2019, 55(12): 10282-10302.
[23]	谷河泉, 赵峰, 季韬, 等. 盐度对镭同位素在海南红树林沉积物解吸行为的影响[J]. 海洋与湖沼, 2015, 46(1):65-76.
[24]	LI Y H, MATHIEU G, BISCAYE P, et al. The flux of ²²⁶Ra from estuarine and continental shelf sediments[J]. Earth and Planetary Science Letters, 1977, 37(2): 237-241.
[25]	WHITEHOUSE G U, JEFFREY M L, DEBBRECHT D J. Differential settling tendencies of clay minerals in saline waters[J]. Clays and Clay Minerals, 1958, 7(1): 1-79.
[26]	LAURIA C D, GODOY M J. Abnormal high natural radium concentration in surface waters[J]. Journal of Environmental Radioactivity, 2002, 61(2): 159-168.
[27]	TACHI Y, SHIBUTANI T, SATI H, et al. Experimental and modeling studies on sorption and diffusion of radium in bentonite[J]. Journal of Contaminant Hydrology, 2001, 47(2): 171-186.
[28]	URSO L, HORMANN V, DIENER A, et al. Modelling partition coefficients of radium in soils[J]. Applied Geochemistry, 2019, 105: 78-86.
[29]	CHARETTE A M, SHOLKVITZ R E. Oxidative precipitation of groundwater-derived ferrous iron in the subterranean estuary of a coastal bay[J]. Geophysical Research Letters, 2002, 29(10):1444.
[30]	SPITERI C, REGNIER P, SLOMP P C, et al. pH-dependent iron oxide precipitation in a subterranean estuary[J]. Journal of Geochemical Exploration, 2005, 88(1): 399-403.
[31]	MORRE S W, REID F D. Extraction of radium from natural waters using manganese-impregnated acrylic fibers[J]. Journal of Geophysical Research, 1973, 78: 8880-8886.
[32]	NATHWANI J S, PHILLIPS C R. Adsorption of ²²⁶Ra by soils in the presence of Ca²⁺ ions: Specific adsorption (II)[J]. Pergamon, 1979, 8(5): 293-299.
[33]	VANDENHOVE H, GIL-GARCíA C, RIGOL A, et al. New best estimates for radionuclide solid-liquid distribution coefficients in soils: Part 2. Naturally occurring radionuclides[J]. Journal of Environmental Radioactivity, 2009, 100(9): 697-703.
[34]	BRIGANTI A, VOLTAGGIO M, TUCCIMEI P, et al. Radium in groundwater hosted in porous aquifers: estimation of retardation factor and recoil rate constant by using NAPLs[J]. SN Applied Sciences, 2020, 2(11):1934.
[35]	SUN Y, TORGERSEN T. Adsorption-desorption reactions and bioturbation transport of ²²⁴Ra in marine sediments: a one-dimensional model with applications[J]. Marine Chemistry, 2001, 74(4): 227-243.
[36]	KREST M J, HARVEY W J. Using natural distributions of short-lived radium isotopes to quantify groundwater discharge and recharge[J]. Limnology and Oceanography, 2003, 48(1): 290-298.
[37]	COLBERT L S, HAMMOND E D. Shoreline and seafloor fluxes of water and short-lived Ra isotopes to surface water of San Pedro Bay, CA[J]. Marine Chemistry, 2008, 108(1): 1-17.
[38]	LI Y H, CHAN L H. Desorption of Ba and ²²⁶Ra from river-borne sediments in the Hudson estuary[J]. Earth and Planetary Science Letters, 1979, 43(3): 343-350.
[39]	KUMAR S, KAR S A, RAWAT N, et al. Distribution coefficients of radionuclides around uranium mining area and effect of different analytical parameters on their determination[J]. Journal of Radioanalytical and Nuclear Chemistry, 2015, 304(2): 727-733.
[40]	WEBSTER T I, HANCOCK J G, MURRAY S A. Modelling the effect of salinity on radium desorption from sediments[J]. Geochimica et Cosmochimica Acta, 1995, 59(12): 2469-2476.
[41]	KRISHNASWAMI S, GRAUSTEIN C W, TUREKIAN K K, et al. Radium, thorium and radioactive lead isotopes in groundwaters: Application to the in situ determination of adsorption-desorption rate constants and retardation factors[J]. Water Resources Research, 1982, 18(6): 1663-1675.
[42]	STYRCHIO C N, BANNER L J, BINZ M C, et al. Radium geochemistry of ground waters in Paleozoic carbonate aquifers, midcontinent, USA[J]. Applied Geochemistry, 2001, 16(1): 109-122.
[43]	STACKELBERG E P, SZABO Z, JURGRNS C B. Radium mobility and the age of groundwater in public-drinking-water supplies from the Cambrian-Ordovician aquifer system, north-central USA[J]. Applied Geochemistry, 2018, 89: 34-48.
[44]	MOISE T, STARINSKY A, KATZ A, et al. Ra isotopes and Rn in brines and ground waters of the Jordan-Dead Sea Rift Valley: enrichment, retardation, and mixing[J]. Geochimica et Cosmochimica Acta, 2000, 64(14): 2371-2388.
[45]	LUO S, KU T, ROBACK R, et al. In-situ radionuclide transport and preferential groundwater flows at INEEL (Idaho): decay-series disequilibrium studies[J]. Geochimica et Cosmochimica Acta, 2000, 64(5): 867-881.
[46]	HORMANN V, FISCHER W H. Estimating the distribution of radionuclides in agricultural soils-Dependence on soil parameters[J]. Journal of Environmental Radioactivity, 2013, 124: 278-286.
[47]	谷河泉, 杜金洲, 吴梅桂, 等. 镭延迟符合计数器(RaDeCC)测量海水中的²²⁴Ra和²²³Ra[J]. 海洋环境科学, 2015, 34(4): 570-577.
[48]	MORRE S W, ARNOLD R. Measurement of ²²³Ra and ²²⁴Ra in coastal waters using a delayed coincidence counter[J]. Journal of Geophysical Research: Oceans, 1996, 101:1321-1329.
[49]	ELSINGER J R, MOORE S W. ²²⁶Ra and ²²⁸Ra in the mixing zones of the Pee Dee River-Winyah Bay, Yangtze River and Delaware Bay Estuaries[J]. Estuarine, Coastal and Shelf Science, 1984, 18(6): 601-613.
[50]	孔凡翠, 沙占江, 杜金洲, 等. 青海湖西岸镭同位素的解吸和扩散特征[J]. 湖泊科学, 2016, 28(5):1103-1114.
[51]	罗浩, 李林蔚, 王锦龙, 等. 钦州湾河流沉积物中镭的解吸行为[J]. 海洋学报, 2019, 41(4):27-41.
[52]	林鸿溢, 李映雪. 分形论:奇异的探索[M]. 北京: 北京理工大学出版社, 1992.
[53]	DRUILLENNEC L T, IELSCH G, BOUR O, et al. Hydrogeological and geochemical control of the variations of ²²²Rn concentrations in a hard rock aquifer: Insights into the possible role of fracture-matrix exchanges[J]. Applied Geochemistry, 2009, 25(3): 345-356.
[54]	SUKANYA S, NOBLE J, JOSEPH S. Factors controlling the distribution of radon (²²²Rn) in groundwater of a tropical mountainous river basin in southwest India[J]. Chemosphere, 2021, 263: 1-14.
[55]	SANTOS O T, BONOTTO M D. ²²²Rn, ²²⁶ Ra and hydroche-mistry in the Bauru Aquifer System, São José do Rio Preto (SP), Brazil[J]. Applied Radiation and Isotopes, 2014, 86: 109-117.
[56]	PAYNE E T, BRENDLER V, OCHS M, et al. Guidelines for thermodynamic sorption modelling in the context of radioactive waste disposal[J]. Environmental Modelling and Software, 2013, 42: 143-156.
[57]	SAJIH M, BRYAN D N, LIVENS R F, et al. Adsorption of radium and barium on goethite and ferrihydrite: A kinetic and surface complexation modelling study[J]. Geochimica et Cosmochimica Acta, 2014, 146: 150-163.
[58]	DONALD L, ARTHUR R C. The thermodynamic properties of radium[J]. Pergamon, 1985, 49(7): 1593-1601.
[59]	DACIDSON R M, DICKSON L B. A porous flow model for steady state transport of radium in groundwater[J]. Water Resources Research, 1986, 22(1): 34-44.
[60]	TRICCA A, PORCELLI D, WASSERBURG J G. Factors controlling the groundwater transport of U, Th, Ra, and Rn[J]. Journal of Earth System Science, 2000, 109(1): 95-108.
[61]	TRICCA A, WASSERBURG J G, PORCELLI D, et al. The transport of U-and Th-series nuclides in a sandy unconfined aquifer[J]. Geochimica et Cosmochimica Acta, 2001, 65(8): 1187-1210.
[62]	BECK J A, RAPAGLIA P J, COCHRAN K J, et al. Radium mass-balance in Jamaica Bay, NY: Evidence for a substantial flux of submarine groundwater[J]. Marine Chemistry, 2007, 106(3): 419-441.
[63]	MORRE S W. Radium isotopes in the Chesapeake Bay[J]. Estuarine, Coastal and Shelf Science, 1981, 12(6): 713-723.

研究者	测定方法	K_d/(mL·g^-1)	固体介质类型
Nathwani^[32]	实验法	10.1~1 779.7	粉质黏土、砂壤土、粉砂壤土、砂土
Vandenhove^[33]	实验法	12~950 000	亚黏土、砂土
Kırıs^[1]	实验法	2 185.9~7 882.9	沉积物
Vandenhove^[14]	实验法	38~446	砂土、壤土、黏土
Gonneea^[20]	实验法	210~475	砂
Rama^[14]	实验法	45	沉积物
Cable^[21]	实验法	0.15~296	石英砂
Briganti^[34]	实验法	0.1~77.9	二氧化锰、沸石、黏土、火山岩
Sun^[35]	实验法	4~85	沉积物
Krest^[36]	实验法	120~280	泥炭层沉积物
Colbert^[37]	实验法	1.2~6.4	长石、角闪石
Beck^[16]	实验法	0.1~1 535	砂
Li^[38]	实验法	235和2 100	沉积物
Kumar^[39]	实验法	1 000	砂土
Webster^[40]	离子交换法	75	高岭石、伊利石等黏土矿物
Liu^[22]	离子交换法	30~3 983	砂
谷河泉^[23]	离子交换法	24~450	粗粉砂、细砂
Urso^[28]	热动力学吸附平衡计算法	42~393	亚黏土、砂土
Krishnaswa^[41]	Rn平衡法	7 100~12 300	结晶岩和长石砂岩
Sturchio^[42]	Rn平衡法	1~10 000	碳酸盐岩
Weaver^[19]	Rn平衡法	16~160	砂岩
Stackelberg^[43]	Rn平衡法	0.2~1 200.0	砂岩和碳酸盐岩

研究者	测定方法	K_d/(mL·g^-1)	固体介质类型
Nathwani^[32]	实验法	10.1~1 779.7	粉质黏土、砂壤土、粉砂壤土、砂土
Vandenhove^[33]	实验法	12~950 000	亚黏土、砂土
Kırıs^[1]	实验法	2 185.9~7 882.9	沉积物
Vandenhove^[14]	实验法	38~446	砂土、壤土、黏土
Gonneea^[20]	实验法	210~475	砂
Rama^[14]	实验法	45	沉积物
Cable^[21]	实验法	0.15~296	石英砂
Briganti^[34]	实验法	0.1~77.9	二氧化锰、沸石、黏土、火山岩
Sun^[35]	实验法	4~85	沉积物
Krest^[36]	实验法	120~280	泥炭层沉积物
Colbert^[37]	实验法	1.2~6.4	长石、角闪石
Beck^[16]	实验法	0.1~1 535	砂
Li^[38]	实验法	235和2 100	沉积物
Kumar^[39]	实验法	1 000	砂土
Webster^[40]	离子交换法	75	高岭石、伊利石等黏土矿物
Liu^[22]	离子交换法	30~3 983	砂
谷河泉^[23]	离子交换法	24~450	粗粉砂、细砂
Urso^[28]	热动力学吸附平衡计算法	42~393	亚黏土、砂土
Krishnaswa^[41]	Rn平衡法	7 100~12 300	结晶岩和长石砂岩
Sturchio^[42]	Rn平衡法	1~10 000	碳酸盐岩
Weaver^[19]	Rn平衡法	16~160	砂岩
Stackelberg^[43]	Rn平衡法	0.2~1 200.0	砂岩和碳酸盐岩
