Geochronology, Geochemistry and Tectonic Significance of Linzizong Group Volcanic Rocks in the Nimu-Jiacha Area, Eastern Lhasa Block,Tibet,China

doi:10.19657/j.geoscience.1000-8527.2019.04.03

Abstract

Abstract:

Lhasa block is featured by extensive Mesozoic-Cenozoic magmatism, which is important for understanding the Neo-Tethyan evolution and the tectonic history of the Tibetan plateau. In this paper, LA-ICP-MS zircon U-Pb dating and whole-rock geochemical analyses of the Bima Formation volcanic rocks in the Nimu-Jiacha area (eastern Lhasa block) were carried out. Zircon U-Pb ages of the Bima Formation volcanic rock are about 55.2-57.6 Ma, which are significantly younger than the published Pima volcanic rock age of 177-195 Ma, and are coeval with the Linzizong Group volcanic rocks (30.4-70.0 Ma). Accordingly, the Bima Formation that was originally thought to be in the area should be redefined as Nianbo Formation of the Linzizong Group. The main volcanic rocks in the study area are basalt, basaltic andesite, andesite and dacite, belonging to the middle-to high-K calc-alkaline series. The volcanic rocks are enriched in LILEs (e.g., Rb, Th, U) and show clear negative anomalies of HFSEs (e.g., Nb, Ta, Zr, Ti), with typical island arc geochemical affinities. The REE patterns reveal LREE enrichments, and no or moderately-negative Eu anomaly. In addition, the Nianbo Formation volcanic rocks in the study area are younger than the Nianbo Formation in the middle-western Lhasa block. Combined with published information, it is indicated that the India-Asia collision progressed from west to east.

Key words: zircon LA-ICP-MS U-Pb dating, geochemistry, Nianbo Formation, Linzizong Group, Lhasa block

CLC Number:

P588.1

WEI Tianwei, YANG Feng, KANG Zhiqiang, WEI Naishao, LIU Di, CAO Yan, LI Daixian, CHEN Huan, CHEN Linhua. Geochronology, Geochemistry and Tectonic Significance of Linzizong Group Volcanic Rocks in the Nimu-Jiacha Area, Eastern Lhasa Block,Tibet,China[J]. Geoscience, 2019, 33(04): 715-726.

Figures/Tables 10

References 64

[1]	潘桂棠, 莫宣学, 侯增谦, 等. 冈底斯造山带的时空结构及演化[J]. 岩石学报, 2006,22(3):521-533.
[2]	JI W Q, WU F Y, CHUNG S L, et al. Zircon U-Pb geochronology and Hf isotopic constraints on petrogenesis of the Gangdese batholith, southern Tibet[J]. Chemical Geology, 2009,262(3/4):229-245. DOI URL
[3]	纪伟强, 吴福元, 锺孙霖, 等. 西藏南部冈底斯岩基花岗岩时代与岩石成因[J]. 中国科学D辑:地球科学, 2009,39(7):849-871.
[4]	莫宣学. 岩浆与岩浆岩:地球深部“探针”与演化记录[J]. 自然杂志, 2011,33(5):255-259.
[5]	莫宣学. 岩浆作用与青藏高原演化[J]. 高校地质学报, 2011,17(3):351-367.
[6]	陈希节, 许志琴, 孟元库, 等. 冈底斯带中段中新世埃达克质岩浆作用的年代学、地球化学及Sr-Nd-Hf同位素制约[J]. 岩石学报, 2014,30(8):2253-2268.
[7]	莫宣学, 赵志丹, 邓晋福, 等. 印度-亚洲大陆主碰撞过程的火山作用响应[J]. 地学前缘, 2003,10(3):135-148.
[8]	刘鸿飞. 拉萨地区林子宗火山岩系的划分和时代归属[J]. 西藏地质, 1993(2):59-69.
[9]	董国臣, 莫宣学, 赵志丹, 等. 拉萨北部林周盆地林子宗火山岩层序新议[J]. 地质通报, 2005,24(6):549-557.
[10]	周肃, 莫宣学, 董国臣, 等. 西藏林周盆地林子宗火山岩⁴⁰Ar/³⁹Ar年代格架 [J]. 科学通报, 2004,49(20):2095-2103.
[11]	HE Shundong, KAPP P, DECELLES P G, et al. Cretaceous-Tertiary geology of the Gangdese Arc in the Linzhou area, southern Tibet[J]. Tectonophysics, 2007,433(1):15-37. DOI URL
[12]	莫宣学. 青藏高原岩浆岩成因研究:成果与展望[J]. 地质通报, 2009,28(12):5-15.
[13]	董国臣. 林周盆地林子宗火山岩及其所含的印度-欧亚大陆碰撞信息研究[D]. 北京:中国地质大学(北京), 2002.
[14]	黄圭成, 李志昌, 邱瑞照, 等. 西藏冈底斯西段狮多地区火山岩的地质地球化学特征[J]. 现代地质, 2004,18(4):511-517.
[15]	CHEN J S, HUANG B C, SUN L S. New constraints to the onset of the India-Asia collision: Paleomagnetic reconnaissance on the Linzizong Group in the Lhasa Block, China[J]. Tectonophysics, 2010,489(1/4):189-209. DOI URL
[16]	黄映聪, 杨德明, 郑常青, 等. 西藏林周县扎雪地区林子宗群帕那组火山岩的地球化学特征及其地质意义[J]. 吉林大学学报(地球科学版), 2005(5):576-580.
[17]	梁银平, 朱杰, 次邛, 等. 青藏高原冈底斯带中部朱诺地区林子宗群火山岩锆石U-Pb年龄和地球化学特征[J]. 地球科学, 2010,35(2):211-223.
[18]	李再会, 郑来林, 李军敏, 等. 冈底斯中段林子宗火山岩⁴⁰Ar-³⁹Ar年龄及其意义 [J]. 矿物岩石地球化学通报, 2009,28(3):223-227.
[19]	李再会, 郑来林, 李军敏, 等. 冈底斯中段林子宗火山岩岩石地球化学特征[J]. 矿物岩石地球化学通报, 2008,27(1):20-27.
[20]	毛素斌, 吴旭铃, 孙国发. 西藏措勤地区年波组岩石地球化学特征[J]. 华东地质, 2005,26(4):235-243.
[21]	于枫, 李志国, 赵志丹, 等. 西藏冈底斯带中西部措麦地区林子宗火山岩地球化学特征及意义[J]. 岩石学报, 2010,26(7):2217-2225.
[22]	谢克家, 曾令森, 刘静, 等. 藏南昂仁县桑桑地区林子宗群火山岩的形成时代和地球化学特征[J]. 地质通报, 2011,30(9):1339-1352.
[23]	ZHU D C, WANG Q, ZHAO Z D, et al. Corrigendum: Magmatic record of India-Asia collision[J]. Scientific Reports, 2015,5:14289. DOI URL
[24]	陈贝贝, 丁林, 许强, 等. 西藏林周盆地林子宗群火山岩的精细年代框架[J]. 第四纪研究, 2016,36(5):1037-1054.
[25]	赵志丹, 莫宣学, SEBASTIEN Nomade, 等. 青藏高原拉萨地块碰撞后超钾质岩石的时空分布及其意义[J]. 岩石学报, 2006,22(4):787-794.
[26]	LING D. Paleocene deep-water sediments and radiolarian faunas: Implications for evolution of Yarlung-Zangbo foreland basin, southern Tibet[J]. Science in China (Series D), 2003,46(1):84-96. DOI URL
[27]	LEE H Y, Chung S L, LO C H, et al. Eocene Neotethyan slab breakoff in southern Tibet inferred from the Linzizong volcanic record[J]. Tectonophysics, 2009,477(1):20-35. DOI URL
[28]	MO X X, HOU Z Q, NIU Y L, et al. Mantle contributions to crustal thickening during continental collision: Evidence from Cenozoic igneous rocks in southern Tibet[J]. Lithos, 2007,96(1):225-242. DOI URL
[29]	MO X X, NIU Y L, DONG G C, et al. Contribution of syncollisional felsic magmatism to continental crust growth: A case study of the Paleogene Linzizong volcanic Succession in southern Tibet[J]. Chemical Geology, 2008,250(1/4):49-67. DOI URL
[30]	WEN D R, LIU D Y, CHUNG S L, et al. Zircon SHRIMP U-Pb ages of the Gangdese Batholith and implications for Neotethyan subduction in southern Tibet[J]. Chemical Geology, 2008,252(3/4):191-201. DOI URL
[31]	宋全友. 措勤盆地林子宗群火山岩地球化学特征[J]. 地质力学学报, 1999,5(2):65-70.
[32]	DING L, KAPP P, WAN X, et al. Paleocene-Eocene record of ophiolite obduction and initial India-Asia collision, south central Tibet[J]. Tectonics, 2005,24(3):TC3001.
[33]	ZHU D C, ZHAO Z D, NIU Y, et al. The origin and pre-Cenozoic evolution of the Tibetan Plateau[J]. Gondwana Research, 2013,23(4):1429-1454. DOI URL
[34]	朱弟成, 莫宣学, 王立全, 等. 新特提斯演化的热点与洋脊相互作用:西藏南部晚侏罗世—早白垩世岩浆作用推论[J]. 岩石学报, 2008,24(2):225-237.
[35]	朱弟成, 赵志丹, 牛耀龄, 等. 拉萨地体的起源和古生代构造演化[J]. 高校地质学报, 2012,18(1):1-15.
[36]	夏代祥, 刘世坤. 西藏自治区岩石地层[M]. 武汉: 中国地质大学出版社, 1997: 1-200.
[37]	闫国强, 丁俊, 黄勇, 等. 西藏山南比马组安山岩形成时代及意义[J]. 金属矿山, 2014(8):91-94.
[38]	KANG Z Q, XU J F, Wilde S A, et al. Geochronology and geochemistry of the Sangri Group Volcanic Rocks, Southern Lhasa Terrane: Implications for the early subduction history of the Neo-Tethys and Gangdese Magmatic Arc[J]. Lithos, 2014,200/201(1):157-168. DOI URL
[39]	冉孟兰, 康志强, 许继峰, 等. 西藏拉萨地块南缘日喀则地区比马组火山岩的年代学、地球化学及地质意义[J]. 地球化学, 2017,46(3):205-218.
[40]	付文春, 康志强, 潘会彬. 西藏冈底斯带地块西段狮泉河地区林子宗群火山岩地球化学特征、锆石U-Pb年龄及地质意义[J]. 地质通报, 2014,33(6):850-859.
[41]	LIU Y S, GAO S, HU Z C, et al. Continental and oceanic crust recycling-induced melt-peridotite interactions in the trans-North China Orogen: U-Pb dating, Hf isotopes and trace elements in zircons from mantle xenoliths[J]. Journal of Petrology, 2010,51:392-399.
[42]	ANDERSEN T. Correction of common lead in U-Pb analyses that do not report ²⁰⁴Pb [J]. Chemical Geology, 2002,192(1/2):59-79. DOI URL
[43]	LUDWIG K. A Plotting and Regression Program for Radiogenic Isotope Data[M]. Berkeley: Berkeley Geochronology Center, 1991: 91.
[44]	YUAN H L, GAO S, LIU X M, et al. Accurate U-Pb age and trace element determinations of zircon by laser ablation-inductively coupled plasma-mass spectrometry[J]. Geostandards & Geoanalytical Research, 2004,28(3):353-370.
[45]	WANG X L, ZHOU J C, QIU J S, et al. LA-ICP-MS U-Pb zircon geochronology of the Neoproterozoic igneous rocks from Northern Guangxi, South China: Implications for tectonic evolution[J]. Precambrian Research, 2006,145(1/2):111-130. DOI URL
[46]	刘颖, 刘海臣. 用ICP-MS 准确测定岩石样品中的40余种微量元素[J]. 地球化学, 1996,25(6):552-558.
[47]	SUN S S, MCDONOUGH W F. Chemical and isotopic systematics of oceanic basalts: implications for mantle composition and processes[J]. Geological Society, London, Special Publications, 1989,42(1):313-345. DOI URL
[48]	COULON C, MALUSKI H, BOLLINGER C, et al. Mesozoic and Cenozoic volcanic rocks from central and southern Tibet:³⁹Ar-⁴⁰Ar dating, petrological characteristics and geodynamical significance [J]. Earth & Planetary Science Letters, 1986,79(3):281-302.
[49]	周肃, 方念乔, 董国臣, 等. 西藏林子宗群火山岩氩-氩年代学研究[J]. 矿物岩石地球化学通报, 2001(4):317-319.
[50]	贾建称, 温长顺, 王根厚, 等. 冈底斯地区林子宗群火山岩岩石地球化学特征及地球动力学意义[J]. 中国地质, 2005,32(3):396-404.
[51]	李皓扬, 钟孙霖, 王彦斌, 等. 藏南林周盆地林子宗火山岩的时代、成因及其地质意义:锆石U-Pb年龄和Hf同位素证据[J]. 岩石学报, 2007,23(2):493-500.
[52]	莫宣学, 董国臣, 赵志丹, 等. 西藏冈底斯带花岗岩的时空分布特征及地壳生长演化信息[J]. 高校地质学报, 2005(03):281-290.
[53]	莫宣学, 潘桂棠. 从特提斯到青藏高原形成:构造-岩浆事件的约束[J]. 地学前缘, 2006,13(6):43-51.
[54]	文丰. 西藏昂仁地区典中组岩石地球化学特征及其意义[J]. 西部探矿工程, 2008,20(6):105-108.
[55]	丁枫, 徐忠彪, 刘寿航, 等. 西藏措勤赤马地区古近系年波组火山岩LA-ICP-MS锆石U-Pb年龄、地球化学特征及其成因[J]. 地质论评, 2017,63(4):1102-1116.
[56]	谢冰晶, 周肃, 谢国刚, 等. 西藏冈底斯中段孔隆至丁仁勒地区林子宗群火山岩锆石SHRIMP年龄和地球化学特征的区域对比[J]. 岩石学报, 2013,29(11):3803-3814.
[57]	CHEN J, HUANG B, YI Z, et al. Paleomagnetic and ⁴⁰Ar/³⁹Ar geochronologic results from the Linzizong Group, Linzhou Basin, Lhasa Terrane, Tibet: Implications to Paleogene paleolatitude and onset of the India-Asia collision [J]. Journal of Asian Earth Sciences, 2014,96(57):162-177. DOI URL
[58]	HUANG W, DUPONTNIVET G, LIPPERT P C, et al. Inclination shallowing in Eocene Linzizong sedimentary rocks from Southern Tibet: correction, possible causes and implications for reconstructing the India-Asia collision[J]. Acta Geologica Sinica, 2013,194(3):1390-1411.
[59]	MO X, ZHAO Z, ZHOU S, et al. Evidence for timing of the initiation of India-Asia collision from igneous rocks in Tibet[M]// AGU. AGU Fall Meeting Abstracts.San Francisco: AGU, 2002.
[60]	TURNER S, ARNAUD N, LIU J, et al. Post-collision, Shoshonitic Volcanism on the Tibetan Plateau: Implications for convective thinning of the lithosphere and the source of ocean island basalts[J]. Journal of Petrology, 1996,37(1):45-71. DOI URL
[61]	DING L, KAPP P, ZHONG D L, et al. Cenozoic volcanism in Tibet: Evidence for a transition from oceanic to continental subduction[J]. Journal of Petrology, 2003,44(10):1833-1865. DOI URL
[62]	潘桂棠, 王立全, 朱弟成. 青藏高原区域地质调查中几个重大科学问题的思考[J]. 地质通报, 2004,23(1):12-19.
[63]	朱弟成, 潘桂棠, 莫宣学, 等. 特提斯喜马拉雅带中段东部三叠纪火山岩的地球化学和岩石成因[J]. 岩石学报, 2006,22(4):804-816.
[64]	康志强, 许继峰, 陈建林, 等. 西藏南部桑日群火山岩的时代:来自晚期马门侵入体的约束[J]. 地球化学, 2010,39(6):520-530.

分析点号	含量/10^-6			Th/U	同位素比值					年龄/Ma
分析点号	Th	U		Th/U	²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ		²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ
14BM-07-01	2 079	2 427	0.86		0.062 00	0.003 41	0.008 65	0.000 19	61.1		3.3	55.5	1.2
14BM-07-02	280	422	0.66		0.086 92	0.007 74	0.009 73	0.000 23	84.6		7.2	62.4	1.5
14BM-07-03	427	494	0.86		0.070 90	0.004 46	0.009 04	0.000 17	69.6		4.2	58.0	1.1
14BM-07-04	351	406	0.86		0.059 33	0.004 55	0.007 55	0.000 26	58.5		4.4	48.5	1.6
14BM-07-05	744	551	1.35		0.063 44	0.005 98	0.008 00	0.000 26	62.5		5.7	51.3	1.6
14BM-07-06	238	383	0.62		0.082 43	0.005 94	0.008 95	0.000 18	80.4		5.6	57.4	1.1
14BM-07-07	2 066	5 051	0.41		0.029 61	0.001 15	0.004 87	0.000 06	29.6		1.1	31.3	0.4
14BM-07-08	397	426	0.93		0.064 99	0.004 11	0.008 20	0.000 17	63.9		3.9	52.6	1.1
14BM-07-09	503	506	0.99		0.066 27	0.004 71	0.008 65	0.000 19	65.2		4.5	55.6	1.2
14BM-07-10	1 653	3 035	0.54		0.027 09	0.001 32	0.004 45	0.000 05	27.1		1.3	28.6	0.3
14BM-07-11	2 223	3 809	0.58		0.026 08	0.001 18	0.004 23	0.000 05	26.1		1.2	27.2	0.4
14BM-07-12	235	450	0.52		0.084 93	0.008 26	0.010 41	0.000 32	82.8		7.7	66.7	2.1
14BM-07-13	156	834	0.19		1.064 09	0.032 25	0.109 56	0.001 67	735.8		15.9	670.2	9.7
14BM-07-14	1 436	2 741	0.52		0.038 62	0.003 10	0.004 98	0.000 12	38.5		3.0	32.0	0.8
14BM-07-15	2 077	3 499	0.59		0.035 80	0.001 72	0.004 86	0.000 06	35.7		1.7	31.2	0.4
14BM-07-16	446	543	0.82		0.074 47	0.005 49	0.009 28	0.000 20	72.9		5.2	59.6	1.3
14BM-07-17	1 598	909	1.76		0.063 87	0.004 88	0.008 35	0.000 22	62.9		4.7	53.6	1.4
14BM-07-18	428	581	0.74		0.066 87	0.006 66	0.008 33	0.000 26	65.7		6.3	53.5	1.6
14BM-07-19	5102	4501	1.13		0.036 65	0.001 53	0.004 68	0.000 06	36.5		1.5	30.1	0.4
14BM-07-20	1 662	3 098	0.54		0.034 78	0.001 69	0.005 03	0.000 07	34.7		1.7	32.3	0.5
14BM-07-21	1 510	2 906	0.52		0.037 54	0.002 40	0.004 24	0.000 09	37.4		2.3	27.3	0.6
14BM-07-22	1 915	2 885	0.66		0.034 78	0.002 38	0.004 72	0.000 08	34.7		2.3	30.4	0.5
14BM-07-23	1 116	2 116	0.53		0.065 02	0.003 79	0.009 06	0.000 36	64.0		3.6	58.1	2.3
14BM-07-24	271	434	0.62		0.177 77	0.010 77	0.023 15	0.000 41	166.1		9.3	147.5	2.6
14BM-07-25	658	636	1.04		0.060 40	0.004 88	0.006 57	0.000 22	59.5		4.7	42.2	1.4
14BM-07-26	4 075	4 438	0.92		0.029 45	0.001 46	0.004 39	0.000 05	29.5		1.4	28.2	0.3
14BM-07-27	482	607	0.79		0.065 47	0.005 56	0.008 25	0.000 20	64.4		5.3	53.0	1.3
14BM-07-28	440	533	0.83		0.074 56	0.006 72	0.008 34	0.000 19	73.0		6.4	53.5	1.2
14BM-07-29	1 166	2 170	0.54		0.037 64	0.001 92	0.004 98	0.000 07	37.5		1.9	32.1	0.5
14BM-07-30	1 957	2 784	0.70		0.032 71	0.001 92	0.004 49	0.000 07	32.7		1.9	28.9	0.4
14BM-14-01	268	404	0.66		0.064 09	0.003 94	0.009 43	0.000 19	63.1		3.8	60.5	1.2
14BM-14-02	286	423	0.68		0.074 28	0.004 56	0.009 82	0.000 16	72.8		4.3	63.0	1.0
14BM-14-03	274	428	0.64		0.076 71	0.004 41	0.009 65	0.000 19	75.0		4.2	61.9	1.2
14BM-14-04	454	467	0.97		0.070 16	0.004 29	0.009 56	0.000 16	68.9		4.1	61.3	1.0
14BM-14-05	267	383	0.70		0.058 46	0.003 73	0.009 03	0.000 16	57.7		3.6	57.9	1.0
14BM-14-06	567	748	0.76		0.061 26	0.003 15	0.008 51	0.000 11	60.4		3.0	54.6	0.7
14BM-14-07	293	424	0.69		0.059 87	0.003 76	0.009 09	0.000 18	59.0		3.6	58.3	1.1
14BM-14-08	216	311	0.69		0.092 69	0.005 96	0.009 35	0.000 17	90.0		5.5	60.0	1.1
14BM-14-09	359	479	28.41		0.121 52	0.000 00	0.015 29	0.000 00	116.4		0.0	97.8	0.0
14BM-14-10	217	355	56.82		0.156 56	0.000 00	0.014 56	0.000 00	147.7		0.0	93.2	0.0
14BM-14-11	242	328	0.74		0.070 91	0.005 04	0.009 04	0.000 19	69.6		4.8	58.0	1.2
14BM-14-12	377	479	0.79		0.060 66	0.003 40	0.008 74	0.000 13	59.8		3.3	56.1	0.8
14BM-14-13	348	450	0.77		0.061 01	0.003 39	0.008 68	0.000 15	60.1		3.2	55.7	1.0
14BM-14-14	319	459	0.69		0.066 81	0.004 10	0.008 80	0.000 14	65.7		3.9	56.5	0.9
14BM-14-15	234	349	0.67		0.065 29	0.004 09	0.008 98	0.000 17	64.2		3.9	57.6	1.1
分析点号	含量/10^-6			Th/U	同位素比值					年龄/Ma
分析点号	Th	U		Th/U	²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ		²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ
14BM-19-01	92	139	0.66		0.067 44	0.004 22	0.009 35	0.000 15	66.3		4.0	60.0	1.0
14BM-19-02	210	220	0.95		0.063 74	0.003 04	0.008 89	0.000 13	62.7		2.9	57.1	0.8
14BM-19-03	67	109	0.61		0.079 58	0.005 52	0.009 11	0.000 18	77.8		5.2	58.5	1.2
14BM-19-04	108	128	0.85		0.071 40	0.004 20	0.009 05	0.000 17	70.0		4.0	58.1	1.1
14BM-19-05	105	198	0.53		0.066 40	0.003 73	0.009 31	0.000 15	65.3		3.6	59.7	0.9
14BM-19-06	102	57	1.78		0.066 86	0.004 32	0.008 63	0.000 19	65.7		4.1	55.4	1.2
14BM-19-07	110	144	0.77		0.063 85	0.004 26	0.008 95	0.000 16	62.8		4.1	57.5	1.0
14BM-19-08	136	85	1.61		0.069 15	0.004 89	0.009 21	0.000 19	67.9		4.6	59.1	1.2
14BM-19-09	121	136	0.89		0.069 55	0.004 77	0.009 24	0.000 19	68.3		4.5	59.3	1.2
14BM-19-10	148	95	1.57		0.065 63	0.004 95	0.009 21	0.000 17	64.5		4.7	59.1	1.1
14BM-19-11	142	176	0.81		0.070 16	0.004 08	0.009 14	0.000 15	68.9		3.9	58.6	1.0
14BM-19-12	189	212	0.89		0.062 11	0.003 75	0.008 83	0.000 14	61.2		3.6	56.7	0.9
14BM-19-13	95	110	0.86		0.069 82	0.004 15	0.009 32	0.000 18	68.5		3.9	59.8	1.1
14BM-19-14	132	122	1.09		0.067 44	0.003 69	0.008 56	0.000 16	66.3		3.5	54.9	1.0
14BM-19-15	94	112	0.84		0.062 54	0.003 99	0.008 64	0.000 17	61.6		3.8	55.5	1.1
14BM-19-16	115	145	0.79		0.067 42	0.004 15	0.009 36	0.000 15	66.3		4.0	60.1	1.0
14BM-19-17	34	86	0.40		0.068 86	0.006 05	0.008 78	0.000 19	67.6		5.7	56.4	1.2
14BM-19-18	149	161	0.93		0.064 23	0.003 96	0.008 99	0.000 16	63.2		3.8	57.7	1.0
14BM-19-19	96	123	0.78		0.077 60	0.004 84	0.009 87	0.000 19	75.9		4.6	63.3	1.2
14BM-19-20	697	113	6.19		0.072 36	0.004 80	0.009 67	0.000 16	70.9		4.5	62.1	1.0
14BM-19-21	87	113	0.77		0.082 53	0.005 81	0.009 54	0.000 17	80.5		5.5	61.2	1.1
14BM-19-22	277	204	1.36		0.066 32	0.003 57	0.008 85	0.000 13	65.2		3.4	56.8	0.8
14BM-19-23	440	325	1.35		0.057 05	0.002 99	0.008 53	0.000 11	56.3		2.9	54.8	0.7
14BM-19-24	134	158	0.85		0.068 43	0.004 52	0.009 26	0.000 14	67.2		4.3	59.4	0.9
14BM-19-25	122	146	0.84		0.068 70	0.004 07	0.008 98	0.000 14	67.5		3.9	57.7	0.9

分析点号	含量/10^-6			Th/U	同位素比值					年龄/Ma
分析点号	Th	U		Th/U	²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ		²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ
14BM-07-01	2 079	2 427	0.86		0.062 00	0.003 41	0.008 65	0.000 19	61.1		3.3	55.5	1.2
14BM-07-02	280	422	0.66		0.086 92	0.007 74	0.009 73	0.000 23	84.6		7.2	62.4	1.5
14BM-07-03	427	494	0.86		0.070 90	0.004 46	0.009 04	0.000 17	69.6		4.2	58.0	1.1
14BM-07-04	351	406	0.86		0.059 33	0.004 55	0.007 55	0.000 26	58.5		4.4	48.5	1.6
14BM-07-05	744	551	1.35		0.063 44	0.005 98	0.008 00	0.000 26	62.5		5.7	51.3	1.6
14BM-07-06	238	383	0.62		0.082 43	0.005 94	0.008 95	0.000 18	80.4		5.6	57.4	1.1
14BM-07-07	2 066	5 051	0.41		0.029 61	0.001 15	0.004 87	0.000 06	29.6		1.1	31.3	0.4
14BM-07-08	397	426	0.93		0.064 99	0.004 11	0.008 20	0.000 17	63.9		3.9	52.6	1.1
14BM-07-09	503	506	0.99		0.066 27	0.004 71	0.008 65	0.000 19	65.2		4.5	55.6	1.2
14BM-07-10	1 653	3 035	0.54		0.027 09	0.001 32	0.004 45	0.000 05	27.1		1.3	28.6	0.3
14BM-07-11	2 223	3 809	0.58		0.026 08	0.001 18	0.004 23	0.000 05	26.1		1.2	27.2	0.4
14BM-07-12	235	450	0.52		0.084 93	0.008 26	0.010 41	0.000 32	82.8		7.7	66.7	2.1
14BM-07-13	156	834	0.19		1.064 09	0.032 25	0.109 56	0.001 67	735.8		15.9	670.2	9.7
14BM-07-14	1 436	2 741	0.52		0.038 62	0.003 10	0.004 98	0.000 12	38.5		3.0	32.0	0.8
14BM-07-15	2 077	3 499	0.59		0.035 80	0.001 72	0.004 86	0.000 06	35.7		1.7	31.2	0.4
14BM-07-16	446	543	0.82		0.074 47	0.005 49	0.009 28	0.000 20	72.9		5.2	59.6	1.3
14BM-07-17	1 598	909	1.76		0.063 87	0.004 88	0.008 35	0.000 22	62.9		4.7	53.6	1.4
14BM-07-18	428	581	0.74		0.066 87	0.006 66	0.008 33	0.000 26	65.7		6.3	53.5	1.6
14BM-07-19	5102	4501	1.13		0.036 65	0.001 53	0.004 68	0.000 06	36.5		1.5	30.1	0.4
14BM-07-20	1 662	3 098	0.54		0.034 78	0.001 69	0.005 03	0.000 07	34.7		1.7	32.3	0.5
14BM-07-21	1 510	2 906	0.52		0.037 54	0.002 40	0.004 24	0.000 09	37.4		2.3	27.3	0.6
14BM-07-22	1 915	2 885	0.66		0.034 78	0.002 38	0.004 72	0.000 08	34.7		2.3	30.4	0.5
14BM-07-23	1 116	2 116	0.53		0.065 02	0.003 79	0.009 06	0.000 36	64.0		3.6	58.1	2.3
14BM-07-24	271	434	0.62		0.177 77	0.010 77	0.023 15	0.000 41	166.1		9.3	147.5	2.6
14BM-07-25	658	636	1.04		0.060 40	0.004 88	0.006 57	0.000 22	59.5		4.7	42.2	1.4
14BM-07-26	4 075	4 438	0.92		0.029 45	0.001 46	0.004 39	0.000 05	29.5		1.4	28.2	0.3
14BM-07-27	482	607	0.79		0.065 47	0.005 56	0.008 25	0.000 20	64.4		5.3	53.0	1.3
14BM-07-28	440	533	0.83		0.074 56	0.006 72	0.008 34	0.000 19	73.0		6.4	53.5	1.2
14BM-07-29	1 166	2 170	0.54		0.037 64	0.001 92	0.004 98	0.000 07	37.5		1.9	32.1	0.5
14BM-07-30	1 957	2 784	0.70		0.032 71	0.001 92	0.004 49	0.000 07	32.7		1.9	28.9	0.4
14BM-14-01	268	404	0.66		0.064 09	0.003 94	0.009 43	0.000 19	63.1		3.8	60.5	1.2
14BM-14-02	286	423	0.68		0.074 28	0.004 56	0.009 82	0.000 16	72.8		4.3	63.0	1.0
14BM-14-03	274	428	0.64		0.076 71	0.004 41	0.009 65	0.000 19	75.0		4.2	61.9	1.2
14BM-14-04	454	467	0.97		0.070 16	0.004 29	0.009 56	0.000 16	68.9		4.1	61.3	1.0
14BM-14-05	267	383	0.70		0.058 46	0.003 73	0.009 03	0.000 16	57.7		3.6	57.9	1.0
14BM-14-06	567	748	0.76		0.061 26	0.003 15	0.008 51	0.000 11	60.4		3.0	54.6	0.7
14BM-14-07	293	424	0.69		0.059 87	0.003 76	0.009 09	0.000 18	59.0		3.6	58.3	1.1
14BM-14-08	216	311	0.69		0.092 69	0.005 96	0.009 35	0.000 17	90.0		5.5	60.0	1.1
14BM-14-09	359	479	28.41		0.121 52	0.000 00	0.015 29	0.000 00	116.4		0.0	97.8	0.0
14BM-14-10	217	355	56.82		0.156 56	0.000 00	0.014 56	0.000 00	147.7		0.0	93.2	0.0
14BM-14-11	242	328	0.74		0.070 91	0.005 04	0.009 04	0.000 19	69.6		4.8	58.0	1.2
14BM-14-12	377	479	0.79		0.060 66	0.003 40	0.008 74	0.000 13	59.8		3.3	56.1	0.8
14BM-14-13	348	450	0.77		0.061 01	0.003 39	0.008 68	0.000 15	60.1		3.2	55.7	1.0
14BM-14-14	319	459	0.69		0.066 81	0.004 10	0.008 80	0.000 14	65.7		3.9	56.5	0.9
14BM-14-15	234	349	0.67		0.065 29	0.004 09	0.008 98	0.000 17	64.2		3.9	57.6	1.1
分析点号	含量/10^-6			Th/U	同位素比值					年龄/Ma
分析点号	Th	U		Th/U	²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ		²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ
14BM-19-01	92	139	0.66		0.067 44	0.004 22	0.009 35	0.000 15	66.3		4.0	60.0	1.0
14BM-19-02	210	220	0.95		0.063 74	0.003 04	0.008 89	0.000 13	62.7		2.9	57.1	0.8
14BM-19-03	67	109	0.61		0.079 58	0.005 52	0.009 11	0.000 18	77.8		5.2	58.5	1.2
14BM-19-04	108	128	0.85		0.071 40	0.004 20	0.009 05	0.000 17	70.0		4.0	58.1	1.1
14BM-19-05	105	198	0.53		0.066 40	0.003 73	0.009 31	0.000 15	65.3		3.6	59.7	0.9
14BM-19-06	102	57	1.78		0.066 86	0.004 32	0.008 63	0.000 19	65.7		4.1	55.4	1.2
14BM-19-07	110	144	0.77		0.063 85	0.004 26	0.008 95	0.000 16	62.8		4.1	57.5	1.0
14BM-19-08	136	85	1.61		0.069 15	0.004 89	0.009 21	0.000 19	67.9		4.6	59.1	1.2
14BM-19-09	121	136	0.89		0.069 55	0.004 77	0.009 24	0.000 19	68.3		4.5	59.3	1.2
14BM-19-10	148	95	1.57		0.065 63	0.004 95	0.009 21	0.000 17	64.5		4.7	59.1	1.1
14BM-19-11	142	176	0.81		0.070 16	0.004 08	0.009 14	0.000 15	68.9		3.9	58.6	1.0
14BM-19-12	189	212	0.89		0.062 11	0.003 75	0.008 83	0.000 14	61.2		3.6	56.7	0.9
14BM-19-13	95	110	0.86		0.069 82	0.004 15	0.009 32	0.000 18	68.5		3.9	59.8	1.1
14BM-19-14	132	122	1.09		0.067 44	0.003 69	0.008 56	0.000 16	66.3		3.5	54.9	1.0
14BM-19-15	94	112	0.84		0.062 54	0.003 99	0.008 64	0.000 17	61.6		3.8	55.5	1.1
14BM-19-16	115	145	0.79		0.067 42	0.004 15	0.009 36	0.000 15	66.3		4.0	60.1	1.0
14BM-19-17	34	86	0.40		0.068 86	0.006 05	0.008 78	0.000 19	67.6		5.7	56.4	1.2
14BM-19-18	149	161	0.93		0.064 23	0.003 96	0.008 99	0.000 16	63.2		3.8	57.7	1.0
14BM-19-19	96	123	0.78		0.077 60	0.004 84	0.009 87	0.000 19	75.9		4.6	63.3	1.2
14BM-19-20	697	113	6.19		0.072 36	0.004 80	0.009 67	0.000 16	70.9		4.5	62.1	1.0
14BM-19-21	87	113	0.77		0.082 53	0.005 81	0.009 54	0.000 17	80.5		5.5	61.2	1.1
14BM-19-22	277	204	1.36		0.066 32	0.003 57	0.008 85	0.000 13	65.2		3.4	56.8	0.8
14BM-19-23	440	325	1.35		0.057 05	0.002 99	0.008 53	0.000 11	56.3		2.9	54.8	0.7
14BM-19-24	134	158	0.85		0.068 43	0.004 52	0.009 26	0.000 14	67.2		4.3	59.4	0.9
14BM-19-25	122	146	0.84		0.068 70	0.004 07	0.008 98	0.000 14	67.5		3.9	57.7	0.9

样品编号	SiO₂	Al₂O₃	TFe₂O₃	MgO	CaO	Na₂O	K₂O	MnO	TiO₂	P₂O₅	烧失量	总量	Y
14BM-01	60.92	16.35	4.46	5.42	6.49	3.50	0.90	0.07	0.50	0.19	1.10	99.89	11.67
14BM-04	50.37	20.70	7.82	4.24	9.55	3.97	1.02	0.16	0.80	0.19	1.06	99.89	18.36
14BM-07	52.70	18.49	8.27	5.19	9.01	2.80	0.91	0.14	0.81	0.20	1.37	99.89	16.61
14BM-12	65.23	17.53	3.91	1.32	3.38	5.03	1.58	0.07	0.50	0.22	1.10	99.87	18.4
14BM-13	65.93	16.78	3.93	1.35	3.40	5.05	1.54	0.06	0.51	0.22	1.09	99.86	18.01
14BM-14	64.97	17.80	7.47	1.74	1.54	0.43	2.65	0.07	0.95	0.07	2.21	99.91	30.38
14BM-19	65.11	17.05	3.97	1.55	4.04	3.73	2.94	0.09	0.45	0.16	0.79	99.89	13.45
样品编号	La	Ce	Pr	Nd	Sm	Eu	Gd	Tb	Dy	Ho	Er	Tm	Yb
14BM-01	18.86	26.63	4.64	17.93	3.303	0.911	2.555	0.404	2.171	0.420	1.155	0.171	1.107
14BM-04	14.81	24.03	4.07	17.17	3.905	1.105	3.207	0.568	3.375	0.680	2.134	0.287	1.875
14BM-07	12.79	19.64	3.61	15.36	3.452	1.067	2.913	0.524	3.134	0.623	1.721	0.271	1.762
14BM-12	20.53	32.91	5.87	23.97	4.879	1.049	3.711	0.626	3.470	0.677	1.924	0.294	1.861
14BM-13	21.06	33.4	5.98	24.18	4.917	1.015	3.71	0.607	3.380	0.655	1.923	0.280	1.796
14BM-14	18.91	31.07	5.52	23.25	5.297	1.197	4.588	0.897	5.754	1.203	3.560	0.584	3.897
14BM-19	18.18	26.14	4.29	16.69	3.339	0.963	2.59	0.428	2.463	0.480	9.129	0.207	1.387
样品编号	Lu	Li	Be	Sc	V	Cr	Co	Ni	Cu	Zn	Ga	Rb	Sr
14BM-01	0.176	9.345	0.873	8.68	83.69	229.30	35.38	145.90	46.22	57.12	15.85	17.46	583.2
14BM-04	0.281	19.52	0.962	16.69	198.00	11.13	22.55	12.01	39.73	113.90	19.74	18.68	650.3
14BM-07	0.281	23.32	0.579	16.85	194.50	12.88	31.54	17.34	18.03	91.98	17.36	18.86	572.4
14BM-12	0.294	17.54	1.443	6.93	51.29	5.80	4.73	3.31	47.05	88.42	18.35	40.46	539.2
14BM-13	0.271	17.11	1.417	6.63	51.22	6.16	4.67	3.12	43.00	86.47	18.28	39.51	537.7
14BM-14	0.638	9.884	1.005	16.03	98.76	13.78	14.86	8.21	31.75	85.28	17.98	62.57	189.5
14BM-19	0.223	16.56	1.036	6.80	58.48	5.59	6.95	2.90	21.17	49.74	16.64	59.12	495.8
样品编号	Zr	Nb	Cs	Ba	Hf	Ta	Pb	Bi	Th	U	δEu	A/CNK	(La/Yb)_N
14BM-01	112.10	4.497	4.214	83.01	3.330	1.711	14.30	0.079	3.323	1.304	0.92	0.88	33.73
14BM-04	27.14	3.529	5.808	327.4	1.137	0.581	30.65	0.676	3.346	0.878	0.93	0.83	8.11
14BM-07	94.92	3.026	19.900	192.2	2.936	0.259	19.05	0.060	2.208	0.601	1.00	0.84	42.99
14BM-12	93.02	8.147	8.362	572.4	3.428	0.608	23.37	0.583	5.066	1.529	0.73	1.09	18.36
14BM-13	72.19	8.106	8.148	476.8	2.812	0.594	22.16	0.542	4.932	1.432	0.70	1.04	14.64
14BM-14	163.20	6.369	5.393	342.7	5.077	0.562	10.37	0.190	4.320	1.066	0.73	2.79	37.78
14BM-19	39.33	5.826	12.400	341.2	1.722	1.729	12.27	0.319	7.681	1.755	0.97	1.02	5.12

样品编号	SiO₂	Al₂O₃	TFe₂O₃	MgO	CaO	Na₂O	K₂O	MnO	TiO₂	P₂O₅	烧失量	总量	Y
14BM-01	60.92	16.35	4.46	5.42	6.49	3.50	0.90	0.07	0.50	0.19	1.10	99.89	11.67
14BM-04	50.37	20.70	7.82	4.24	9.55	3.97	1.02	0.16	0.80	0.19	1.06	99.89	18.36
14BM-07	52.70	18.49	8.27	5.19	9.01	2.80	0.91	0.14	0.81	0.20	1.37	99.89	16.61
14BM-12	65.23	17.53	3.91	1.32	3.38	5.03	1.58	0.07	0.50	0.22	1.10	99.87	18.4
14BM-13	65.93	16.78	3.93	1.35	3.40	5.05	1.54	0.06	0.51	0.22	1.09	99.86	18.01
14BM-14	64.97	17.80	7.47	1.74	1.54	0.43	2.65	0.07	0.95	0.07	2.21	99.91	30.38
14BM-19	65.11	17.05	3.97	1.55	4.04	3.73	2.94	0.09	0.45	0.16	0.79	99.89	13.45
样品编号	La	Ce	Pr	Nd	Sm	Eu	Gd	Tb	Dy	Ho	Er	Tm	Yb
14BM-01	18.86	26.63	4.64	17.93	3.303	0.911	2.555	0.404	2.171	0.420	1.155	0.171	1.107
14BM-04	14.81	24.03	4.07	17.17	3.905	1.105	3.207	0.568	3.375	0.680	2.134	0.287	1.875
14BM-07	12.79	19.64	3.61	15.36	3.452	1.067	2.913	0.524	3.134	0.623	1.721	0.271	1.762
14BM-12	20.53	32.91	5.87	23.97	4.879	1.049	3.711	0.626	3.470	0.677	1.924	0.294	1.861
14BM-13	21.06	33.4	5.98	24.18	4.917	1.015	3.71	0.607	3.380	0.655	1.923	0.280	1.796
14BM-14	18.91	31.07	5.52	23.25	5.297	1.197	4.588	0.897	5.754	1.203	3.560	0.584	3.897
14BM-19	18.18	26.14	4.29	16.69	3.339	0.963	2.59	0.428	2.463	0.480	9.129	0.207	1.387
样品编号	Lu	Li	Be	Sc	V	Cr	Co	Ni	Cu	Zn	Ga	Rb	Sr
14BM-01	0.176	9.345	0.873	8.68	83.69	229.30	35.38	145.90	46.22	57.12	15.85	17.46	583.2
14BM-04	0.281	19.52	0.962	16.69	198.00	11.13	22.55	12.01	39.73	113.90	19.74	18.68	650.3
14BM-07	0.281	23.32	0.579	16.85	194.50	12.88	31.54	17.34	18.03	91.98	17.36	18.86	572.4
14BM-12	0.294	17.54	1.443	6.93	51.29	5.80	4.73	3.31	47.05	88.42	18.35	40.46	539.2
14BM-13	0.271	17.11	1.417	6.63	51.22	6.16	4.67	3.12	43.00	86.47	18.28	39.51	537.7
14BM-14	0.638	9.884	1.005	16.03	98.76	13.78	14.86	8.21	31.75	85.28	17.98	62.57	189.5
14BM-19	0.223	16.56	1.036	6.80	58.48	5.59	6.95	2.90	21.17	49.74	16.64	59.12	495.8
样品编号	Zr	Nb	Cs	Ba	Hf	Ta	Pb	Bi	Th	U	δEu	A/CNK	(La/Yb)_N
14BM-01	112.10	4.497	4.214	83.01	3.330	1.711	14.30	0.079	3.323	1.304	0.92	0.88	33.73
14BM-04	27.14	3.529	5.808	327.4	1.137	0.581	30.65	0.676	3.346	0.878	0.93	0.83	8.11
14BM-07	94.92	3.026	19.900	192.2	2.936	0.259	19.05	0.060	2.208	0.601	1.00	0.84	42.99
14BM-12	93.02	8.147	8.362	572.4	3.428	0.608	23.37	0.583	5.066	1.529	0.73	1.09	18.36
14BM-13	72.19	8.106	8.148	476.8	2.812	0.594	22.16	0.542	4.932	1.432	0.70	1.04	14.64
14BM-14	163.20	6.369	5.393	342.7	5.077	0.562	10.37	0.190	4.320	1.066	0.73	2.79	37.78
14BM-19	39.33	5.826	12.400	341.2	1.722	1.729	12.27	0.319	7.681	1.755	0.97	1.02	5.12
